FEATURES

6 5
4
7
Radial Engineering Ltd.
3 2
8
2
1. InpUT – ¼" jack used to connect your
instrument to the AC-Driver.
2. LEvEL – Controls the output level of
both the XLR and the ¼" outputs.
3. noTch – Sets the center frequency
for the notch filter. Used to eliminate
feedback.
4. noTch Q – 3-position switch bypasses
the notch filter or selects between a
normal or extra-deep notch. Works in
conjunction with the notch frequency
control.
5. 180° phASE REvERSE – Used to
1
reduce on-stage feedback by reversing
the polarity of the XLR output.
6. Low cUT – Variable filter rolls off
excessive low frequencies and controls
bass resonance.
7. oUTpUT – ¼" post-eq output used to
feed an on-stage amplifier.
8. MUTE SwITch And LEd – Footswitch
turns off all outputs except the tuner out.
Used for quiet on-stage tuning.
AC-Driver™ User Guide
