FEATURE SET
The Radial PRO DI is a very simple yet effective device. It features a ¼" input connector that connects to the source or
instrument, a ¼" thru-put connector that connects the instrument to the amplifier and finally, a low impedance balanced
XLR output connector that provides a direct and transformer-isolated signal to the mixer. A -15dB input PAD switch and
output ground lift switch are also available to process the signal.
1/4" hi-Z Instrument input:
connection for instruments
like guitar and bass.
-15dB PAD:
reduces input level to prevent distortion
from ultra-high output devices.
Radial Engineering
Ground lift:
lifts ground from pin-1
on the XLR output.
Rugged packaging:
14 gauge steel enclosure, double sided
PC board and a full bottom foam pad.
Instrument thru-put:
connect to on-stage
amplifier.
2
True to the Music
XLR output:
balanced, low-Z
mic-level output.
