TUnER – Always-on buffered output
is used with the mute footswitch for
quiet on-stage tuning.
10. BALAncEd oUTpUT – XLR line
level output connects directly to a
powered PA speaker or console.
11. LIFT – Ground lift switch disconnects
pin-1 at the XLR output to remove
buzz and hum.
12. 9vdc – Connection for 9-12 volt DC
(center pin negative) power supply.
13. 14-GAUGE STEEL – I-Beam
construction prevents the circuit
board from being torqued which
could lead to part failure.
14. connEcToRS – Glass-filled nylon
14
XLR connector with large nickel-
silver pin contacts. Tougher than
steel.
15. cIRcUIT BoARd – Double-sided
military spec for greater durability
15
and full ground plane to reduce
radio frequency interference.
