SpaNet SV2 Installation & Technical Manual page 4

SV Series Overview
Mains Power
Terminal Block
Mains Power
Cable Entry
Points
Wall Mount
Bracket
Coupling
(tail & nut)
SV Series Spa Controls
Fuse 1
Heater Connection
(Phase 3 Loads)
Terminal Block
Mounting Foot
Fuse 2 Fuse 3
(Phase 2 Loads) (Phase 1 Loads)
Earth Bonding Heater Tube
Terminal
3
Low Voltage Connections
(12V)
keypads, lights, in-pool sensor
digital/analog expand ports
Heartbeat LED
DIP Switch Bank
Wall Mount Bracket
AMP Power Outlets
(230-240V AC)
for spa accessories:
circ, o /uv, air blower
3
jet pumps, auxiliaries
Coupling
(tail & nut)
Heater Cover Plate
(remove to access
heater connections)
