SpaNet SV2 Installation & Technical Manual page 3

SV Series Specifications
Electrical Specifications
Model No Max Maximum Multi
Current Phase Current
SV2 15A -
SV3 45A -
SV2-VH 15A 16A per phase
SV3-VH 45A 25A per phase
SV4-VH 60A 25A per phase
* Range of acceptability (+/-6%)
Output Ratings
Outlet Max Current Output Voltage
Circ 2A 230-240V AC
O3/UV 2A 230-240V AC
Blower 6.3A 230-240V AC
Pump 1 12A 230-240V AC
Pump 2 12A 230-240V AC
Mains 1 ^ 12A 230
Pump 3 * 12A 230-240V AC
Pump 4 # 12A 230-240V AC
Mains 2 *^ 12A 230
~
Light 1 1A 12V AC
~
Light 2 * 1A 12V AC
* Outlets not available on SV2 / SV2-VH models
# Outlet not available on SV2 / SV2-VH / SV3 / SV3-VH models
^ Dedicated mains power outlets (always ON)
~ 1A maximum current draw. This is split between keypads, expand ports and light sockets.
Each socket is rated to 1A maximum so the full 1A can be drawn from a single socket if required.
SV Series Spa Controls
Input Voltage Input Voltage
Single Phase* Three Phase*
230-240V AC 400-415V AC
230-240V AC 400-415V AC
230-240V AC 400-415V AC
230-240V AC 400-415V AC
230-240V AC 400-415V AC
Hz Typical Accessory
50/60 Small Circulation Pump
50/60 Ozone Generator / UV Sanitiser
50/60 Air Blower
50/60 2 Spd Jet Pump / 1 Spd Jet Pump
50/60 1 Speed Jet Pump
240V AC 50/60 ains power outlet
- M
50/60 2 Spd Jet Pump / 1 Spd Jet Pump
50/60 1 Speed Jet Pump
240V AC 50/60 ains power outlet
- M
LED Light
LED Light
Hz Heater Size
50/60 2kW
50/60 3kW
50/60 3kW Variable
50/60 6kW Variable
50/60 6kW Variable
(always on)
(always on)
2
System Specifications
All Models (SV2/SV3/SV2-VH/SV3-VH/SV4-VH)
Maximum Controlled Temperature
Thermal Cut-Out
Maximum Ambient Temperature
Minimum Flow Rate
RCD trip rating
Weight (without cable)
Dimensions (with couplings)
Enclosure
Operating Temperature
Storage Temperature
Humidity
o
41 C
o o
47 C +/-3 C
o
40 C
65 L/min
30mA
5kg
544x309x90mm
IPx5
o o
0 C to 40 C
o o
-25 C to 85 C
up to 85% RH
(non condensing)
