OpenEye OE-C9616 Quick Start Manual

CONNECTIONS
6
5
1
2
3
NOTE It is not recommended to record coninuously
to the microSD card.
Pink
1
Green
2
3
4
5
23221 E Knox Ave
Liberty Lake, WA 99019
509.232.5261
ww.openeye.net

OE-C9616 / OE-C9716 Connections

1 DC12V +
Power 1
2 DC12V -
For network and PoE
RJ-45 2
connections
Insert the microSD card inot
microSD card
3 the card slot to store video
slot
and images
1 Alarm Out +
2 Alarm Out -
3 Alarm In +
4
Alarm and
4 4 Alarm In -
Audio I/O
5 GND
6 Audio Out
7 Audio In
Built-in
5 Audio In
microphone
Press and hold this button
Reset button 6 for 20 seconds to reset the
camera to factory defaults
Speaker 7 Audio Out
OE-C9716 Outdoor Function Cable
Pink Audio In
Audio I/O 1
Green Audio Out
Power (DC12V
Black DC12V +
2-pin terminal 2
Red DC12V -
block)
1 Alarm In +
Alarm I/O
2 Alarm In -
(4-pin terminal 3
3 Alarm Out +
block)
4 Alarm Out -
GND 4 Ground connection
For network and PoE
RJ-45 5
connections
Copyright ©2015 OpenEye.
All Rights Reserved. Information contained in this document is
subject to change without prior notice. OpenEye does its best to
provide accurate information but cannot be held responsible for
typos or mistakes.
QUICK START GUIDE
OE-C9616 & OE-C9716 | Mini Fisheye IP
Camera
This quick start guide is a reference for users to install and operate your
OpenEye camera and only provides basic information on the camera's settings
and operation. Before attempting to connect, configure and operate your
OpenEye camera, please read the user manual thoroughly.
