OpenEye OE-C9616 User Manual

Hide thumbs Also See for OE-C9616:
Table of Contents

Advertisement

Quick Links

6MP 360 Degree IP Camera
User Manual
Cameras
OE-C9616
OE-C9716
www.openeye.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OE-C9616 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for OpenEye OE-C9616

Summary of Contents for OpenEye OE-C9616

  • Page 1 6MP 360 Degree IP Camera User Manual Cameras OE-C9616 OE-C9716 www.openeye.net...
  • Page 2 The information in this document is subject to change without notice. The information in this publication i of the use of this information remains with recipient. In no event shall OPENEYE be liable for any direct, consequential, incidental, special, punitive, or other damages whatsoever (including without limitation,...

  • Page 3: Important Safeguards

    Important Safeguards 1. Read Instructions Read all of the safety and operating instructions before using the product. 2. Retain Instructions Save these instructions for future reference. 3. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty.
  • Page 4 Regulation This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This symbol on the product or on its packaging indicates that this product shall not be treated as household waste in accordance with Directive 2002/96/EC.

  • Page 5: Table Of Contents

    Waterproof Cable Connections for Outdoor Installation ................13 Function Cable ............................ 13 IP66 Ethernet Cable..........................14 SETUP AND CONFIGURATION ....................... 15 OpenEye Network Camera manager ....................... 15 Installation ............................15 Starting Network Camera Manager ..................... 15 Camera Configuration ..........................17 Device Addressing ..........................
  • Page 6 Video Frame Rate ..........................32 Video Compression ..........................33 ADVANCED ............................ 34 System Setting ............................34 Network Setup ............................ 34 Network Advanced ..........................34 Network Security ..........................35 Alarm Application ..........................36 Tampering and Network Failure Detection ................... 37 Mail, HTTP, and FTP Setup ......................... 38 SD Card ..............................

  • Page 7: Introduction

    INTRODUCTION OVERVIEW The OE-C9616 and OE-C9716 are ultra-compact 360 degree cameras, delivering superior IP video quality. With a small form factor, these 6MP cameras are unobtrusive while capturing activity in all directions. Both camera models come with 4 IR LEDs to enhance the quality of nighttime images.

  • Page 8: Connections

    Before proceeding, please check that the box contains the items listed here. If any item is missing or has defects, do not install or operate the product and contact your dealer for assistance. OE-C9616 (left) / OE-C9716 (right) IP Camera Self-Tapping Screw (x3)

  • Page 9: Dimensions

    DIMENSIONS OE-C9616 INDOOR OE-C9716 OUTDOOR 33690AA...

  • Page 10: Removing The Camera Cover

    REMOVING THE CAMERA COVER Loosen the security screws with the included torx tool to remove the camera cover.

  • Page 11: Connections

    CONNECTIONS Connection Definition DC12V + Power Power connection DC12V - RJ-45 For network and PoE connections microSD card slot Insert the microSD card into the card slot to store video and images Alarm out + Alarm out - Alarm in + Alarm and Audio I/O Alarm In - Ground...

  • Page 12: Alarm I/O Connections

    ALARM I/O CONNECTIONS The OE-C9616 and OE-C9716 are equipped with alarm and audio input / output capabilities for alarm application. Refer to alarm pin definition below to connect alarm devices to the IP camera if desired. Definition Alarm out +...

  • Page 13: Waterproof Cable Connections For Outdoor Installation

    WATERPROOF CABLE CONNECTIONS FOR OUTDOOR INSTALLATION Follow the instructions below to waterproof the connectors of different types of cables. The supported cables are shown below. FUNCTION CABLE 1. Connect the desired external devices to the function cable and coat the joints with silicone gel.

  • Page 14: Ip66 Ethernet Cable

    IP66 ETHERNET CABLE For the IP66 Ethernet cable, use an Ethernet plug for connection to prevent water damage. 1. Remove the connector form the Ethernet plug, and then loosen the thread-lock sealing nut on the plug. 2. Thread the Ethernet cable through the thread lock sealing nut and the plug. 3.

  • Page 15: Setup And Configuration

    The Network Camera Manager software is pre-installed on all OpenEye Recorders, and included on the software CD with all OpenEye IP cameras. It is also available for download on the OpenEye website.
  • Page 16 3. Enter the Username and Password for the camera. The username and password are case sensitive. It is strongly recommended that the password be changed after the initial setup to prevent unauthorized access. The default username and password for OpenEye IP cameras are as follows.

  • Page 17: Camera Configuration

    CAMERA CONFIGURATION DEVICE ADDRESSING The functions on the Device Addressing tab allow you to find, configure, and view network cameras. Finding Network Devices 1. Click Find Devices on the Device Addressing tab. 2. To narrow your search by Camera Model, Project, or Camera Name, select your desired criteria from the appropriate lists.

  • Page 18: Connecting To The Camera

    CONNECTING TO THE CAMERA 1. Locate the camera on the IP Finder list. 2. Double-click the camera to open the Viewer software in your web browser. 3. Click Browse in the pop-up window. 4. Log in to the camera with the appropriate Username and Password. Note The default Username Password...

  • Page 19: Connecting Over The Internet

    RTSP, however, is not suitable for transmission between two locations that are behind different routers. In this case, the client (for example, the OpenEye HVR or NVR server software) connects to the camera, and then requests a stream. The camera uses that connection to return a stream, but...

  • Page 20: Viewer Software

    VIEWER SOFTWARE To access the setup menu, you need to install the viewer software on your PC or recorder. The viewer software will install automatically the first time you connect to the camera. If your internet in settings. If your internet browser asks for permission to install the ActiveX control, you must allow the ActiveX control to continue the installation.

  • Page 21: Live

    LIVE Full Screen This will display the live feed in full screen. Snapshot Click the button, and a JPEG snapshot will automatically be saved in the appointed place. The default location is: C:\. Note If you are using Windows Vista or 7, you will need to change the Snapshot location. Windows UAC does not allow internet programs to write directly to C:\ for security reasons.

  • Page 22: Setup

    SETUP The Setup menu includes System Settings, Picture Setup, and Streaming Settings. Note The Setup menu displays limited setup options. For a complete list of setup options, see the Advanced section. SYSTEM SETTING CAMERA NAME Host Name The Host Name is used to identify the camera on your system. If camera based Motion Detection is enabled and is set to send alarm message by Mail/FTP, the host name entered here will display in the alarm message.

  • Page 23: Ip Address

    Every network device has a unique Media Access Control (MAC) address that can be used for identification. The MAC address is located on the bottom of each camera, and on the box label (OpenEye Network Camera Manager also displays the MAC address for identification). Record Note If no DHCP is available, the camera will default to a static IP address of 192.168.0.250 after 4...
  • Page 24 4. Click Apply to confirm the new setting. When using static IP address to log in to the IP Camera, you can access it either through OpenEye IP Finder software or type the IP address directly in the address bar of your Internet Explorer.

  • Page 25: User Setup

    USER SETUP Admin Password Manage the password for the Administrator account. 1. Type a new Administrator Password, and then type again to confirm the password. 2. Click Save. Add User The user name and passwords are limited to 16 characters with no spaces permitted. There is a maximum of twenty user accounts.

  • Page 26: File Location

    Use the Camera Tab section to modify picture settings for the camera. The sample image will change as you modify the picture settings. Note These settings can drastically affect the camera image. OpenEye suggests that these settings are only modified by a CCTV professional, or at the instruction or a technical support representative.

  • Page 27: White Balance

    White Balance Use the white balance setting to change color representation in difficult lighting conditions. Auto White balance works within its color temperature range and calculates the best-fit white balance. Auto-tracing white balance, the camera removes the signals within a range of 2000K to 10000K, which helps to even out the bright white portions of an image.

  • Page 28: Fisheye Setup

    FISHEYE SETUP To set the Edge Dewarping type: 1. In the Advanced menu, under Picture Settings, click Fisheye Setting. 2. Choose a Dewarping type:  Edge Camera Dewarping  Client Side Dewarping 3. Click Save. 4. Choose an Installation type: ...

  • Page 29: Motion Detection

    MOTION DETECTION Use the Motion Detection menu to configure the motion detection window(s). Here, Motion Detection can be turned On or Off, and other general settings can be specified. 1. Use the Motion Detection dropdown to select a motion detection preset (1-4). If choosing an additional preset after 1, check the On checkbox.

  • Page 30: Streaming Settings

    STREAMING SETTINGS VIDEO RESOLUTION The camera provides eight codec options under video resolution (two single streaming options, two sets of dual streaming options, two sets of tri-streaming options, and two sets of quad-streaming options):  H.264 Only  MJPEG Only ...
  • Page 31 P-Frames between each I-frame; increasing the file size of the stream, but decreasing the risk of video decoding errors. OpenEye recommends setting the GOP to be approximately twice the frame rate (e.g.: if the frame rate is 10 IPS, then set the GOP to 20). ...

  • Page 32: Video Frame Rate

    VIDEO FRAME RATE Setting the camera to transmit fewer frames can save bandwidth. Use the Frame Rate Control screen to adjust the frame rate of each stream. Each of the MJPEG and H.264 streams can have a separate frame rate setting from 1 to 30 frames per second.

  • Page 33: Video Compression

    VIDEO COMPRESSION You can select an MJPEG / H.264 compression mode on the video compression page appropriate for your application. You can also select to display compression inflation on the Live Screen. H.264 compression settings include:  1024kbps, highest compression, lowest quality ...

  • Page 34: Advanced

    ADVANCED SYSTEM SETTING NETWORK SETUP The Network Setup settings will automatically be set at the recommended default after the camera connection is made. DDNS DDNS (Dynamic Domain Name Service) is a service that allows a connection to an IP address using a hostname (URL) address instead of a numeric IP address.

  • Page 35: Network Security

    UPnP (Universal Plug N’ Play) Enable UPnP When enabled, the camera will appear in My Network Places on Windows computers running UPnP on the same network. Enable UPnP Port Forwarding When enabled, the camera will attempt to open the web server port on the router automatically.

  • Page 36: Alarm Application

    ALARM APPLICATION The alarms menu is where alarm connections are configured. Alarm Switch Designate when the alarm will be active; Off, On, or By Schedule. Alarm Type Designate if the alarm is normally open or normally closed.  NO stands for Normally Open. ...

  • Page 37: Tampering And Network Failure Detection

    TAMPERING AND NETWORK FAILURE DETECTION Tampering Alarm Turn the Tampering Alarm On, Off, or On By Schedule. Tampering Duration Designate the amount of time (in seconds) that tampering must occur in order for a Tampering Alarm to activate. Triggered Action Designate the actions that will occur upon a Tampering Alarm activating.

  • Page 38: Mail, Http, And Ftp Setup

    Password and E-mail Address settings. For SMTP server, contact your network service provider for more specific information. SD CARD All OpenEye IP cameras include an integrated Load Device Information Displays the storage total size and free space information of the Current Recording Partition Amount of space designated for recording on the microSD card.

  • Page 39: Network Share

    NETWORK SHARE Network Share is a network protocol that runs a variety of different system platforms, allowing for file sharing between computers operating on Windows and computers operating on Linux. This serves as an additional storage type. Configuration requires the host IP address, share name, and credentials. Once configured, cameras can record events to the network share.

  • Page 40: Recording Schedule

    RECORDING SCHEDULE The recording schedule allows you t Network Sharing. Recording This section allows you to define recording schedules for the camera. To set up continuous recording: 1. Select type of Recording Storage.  microSD card  Network Share: save recorded data to the designated Network Share location.
  • Page 41 Schedule This section allows you to establish schedules to use in other section. 1. Select a Schedule set (1-10). 2. Check the desired week day check boxes. 3. Select Day or Night. 4. Designate a Start Time and Duration. 5. Click Save. Interval Recording Interval recording allows you to record in consistent intervals and save the files for later viewing.

  • Page 42: Maintenance

    MAINTENANCE On the Maintenance page you can export the cameras current configuration, or import the configuration for a camera. Use the factory default page to reset the IP Camera to factory default settings if necessary. Note Do not import configuration files from different models of cameras. Configuration Export Configuration 1.

  • Page 43: Software

    SOFTWARE Note Make sure the software upgrade file is available before starting the software upgrade. 1. Click Browse and find the upgrade file. Note Do not change the file name, or the system will fail to find the file. 2. Select the file name from the list under Step 2. 3.

  • Page 44: Streaming Setting

    STREAMING SETTING AUDIO Audio Input Grain sets the amplification that the camera applies to the incoming audio before transmitting. Audio Output Delay Sets a delay in the audio transmission. This is used when there is significant lag in video transmission to help sync the audio and video. Volume Sets the audio output volume level (for listening to live audio).

  • Page 45: Camera Specifications

    CAMERA SPECIFICATIONS Camera Model OE-C9616 OE-C9716 Maximum Resolution 6MP (3027x2048) Image Sensor IMX-178 H.264 (MPEG-4 Part 10/AVC) Baseline / Main Profile / High Profile / SVC / Video Compression MJPEG Frame Rate H.264 6MP @ 25/30 IPS ONVIF Profile S...
  • Page 46 All rights reserved. No part of this publication may be reproduced by any means without written permission from OpenEye. The information in this publication is believed to be accurate in all respects. However, OpenEye cannot assume responsibility for any consequences resulting from the use thereof.
