OpenEye OE-C97512 User Manual

12mp ultra high-definition fisheye 360 ip camera
Hide thumbs Also See for OE-C97512:
Table of Contents

Advertisement

Quick Links

12MP ULTRA HIGH-DEFINITION
FISHEYE 360° IP CAMERA
USER MANUAL
OE-C97512

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OE-C97512 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for OpenEye OE-C97512

Summary of Contents for OpenEye OE-C97512

  • Page 1 12MP ULTRA HIGH-DEFINITION FISHEYE 360° IP CAMERA USER MANUAL OE-C97512...
  • Page 2 The information in this publication is provided “as is” without warranty of any kind. The entire risk arising out of the use of this information remains with recipient. In no event shall OPENEYE be liable for any direct, consequential, incidental, special, punitive, or other damages whatsoever (including without limitation,...
  • Page 3 Important Safeguards Read Instructions Read all of the safety and operating instructions before using the product. Retain Instructions Save these instructions for future reference. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty. Installation Do not place or mount this product in or on an unstable or improperly supported location.
  • Page 4 Regulation This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........................5 Overview ..............................5 Product Features ..........................5 CONNECTIONS ..........................6 Camera Box Contents ..........................6 Dimensions ............................... 7 Bottom of Camera ............................. 8 Removing the Camera Cover ........................9 Connections ............................10 Ethernet Cable Connection ........................11 Weather Resistant Cable Connector ......................

  • Page 6: Introduction

    (camera side) encoding. The Smart Compression option reduces storage requirements by up to 70% while maintaining high resolution video allowing you to meet video retention and resolution requirements for less. The OE-C97512 is IK10 rated and comes in IP66-rated weatherproof housing.

  • Page 7: Connections

    Before proceeding, please check that the box contains the items listed here. If any item is missing or has defects, do not install or operate the product and contact your dealer for assistance. OE-C97512 IP Camera Plastic Anchors and Screws Quick Start Guide...

  • Page 8: Dimensions

    DIMENSIONS 36870AD...

  • Page 9: Bottom Of Camera

    BOTTOM OF CAMERA...

  • Page 10: Removing The Camera Cover

    REMOVING THE CAMERA COVER Press locking tab and slide cover forward to remove the camera cover. 36870AD...

  • Page 11: Connections

    CONNECTIONS Cable Connections RJ-45 Data Connection & PoE Power Audio In Audio I/O Audio Out...

  • Page 12: Ethernet Cable Connection

    ETHERNET CABLE CONNECTION Connect one end of the CAT 5 Ethernet cable to the RJ-45 connector of the camera and the other end of the cable to the network switch or recorder. Check the status of the link indicator and activity indicator LEDs. If the LEDs are unlit, check the LAN connection.

  • Page 13: Weather Resistant Cable Connector

    WEATHER RESISTANT CABLE CONNECTOR This camera features an IP66-rated weather resistant connector. For unprotected outdoor connections, screw the connector on the included Ethernet camera cable onto the camera dongle. If your installation location does not require a water-resistant connection, loosen and slide the connector back on the cable until it’s out of the way.

  • Page 14: Network Camera Manager Software

    NETWORK CAMERA MANAGER SOFTWARE OpenEye Network Camera Manager (NCM) is a software tool that allows you to quickly and easily connect and configure your OpenEye IP Cameras. This software allows you to assign IP addresses, configure video settings, and update firmware on multiple cameras at once.
  • Page 15 Launch from Apex Linux Recorders 1. In the Apex Settings menu, click Launch Support Tools. 2. Click the Network Camera Manager icon.

  • Page 16: Camera Configuration

    CAMERA CONFIGURATION DEVICE ADDRESSING The functions on the Device Addressing tab allow you to find, configure, and view network cameras. Finding Network Devices 1. Click Refresh to reload the Device List. 2. To narrow your search by Camera Model and Network Location, use the Model Filter and Networks dropdowns.
  • Page 17 2. Type the Username and Password for the camera. The username and password are case sensitive. It is strongly recommended that the password be changed after the initial setup to prevent unauthorized access. The default username and password for OpenEye IP cameras are as follows: Username –...

  • Page 18: Setup & Configuration

    SETUP & CONFIGURATION CONNECTING TO THE CAMERA 1. Locate the camera on the Device List. 2. Click Load to open the camera in the web viewer. 3. Log in to the camera with the appropriate Username and Password. The default Username is “admin” and the default Password is “1234”. The username and Note password are case sensitive.

  • Page 19: Video Settings

    VIDEO SETTINGS The Video Settings menu configures the camera’s basic settings, including frame rate, bitrate, and the streaming codecs. 1. Use the dropdown menus to configure the Video Orientation, Sharpness, and Wide Dynamic Range. 2. Click Apply to save each selection. 3.

  • Page 20: Live

    LIVE The camera displays a live view using the MJPEG stream for setup purposes. Proportional – Select the image ratio for the live preview image (Original, Stretch, Scale). Image – Links to the Image setup section. See Image setup for full details. 36870AD...

  • Page 21: Setup

    Every network device has a unique Media Access Control (MAC) address that can be used for identification. The MAC address is located on the bottom of each camera, and on the box label (OpenEye Network Camera Manager also displays the MAC address for identification). Record your camera’s MAC address for identification in the future.

  • Page 22: Network Settings

    NETWORK SETTINGS The Network setting allows you to configure the connected camera network settings. Network DHCP/Static IP/PPPoE You can use the dropdown menu to choose to use a static (fixed) IP address, PPPoE, or a dynamic IP address (assigned by a DHCP server or router) for the camera.
  • Page 23 IPv6 Address Configuration When using a static IP address to log in to the IP Camera, you can access it either through OpenEye IP Finder software or type the IP address directly in the address bar of your Internet Explorer.
  • Page 24 Port To configure relevant port numbers, manually type numbers into HTTP Port, HTTPS Port and RTSP Port, then click Save. HTTP Port – Configure your relevant port number. If the HTTP port number has been occupied already, a “Port conflicts” message will display. Note Ports 23, 81, 82, 85, 3260, and 49152 are occupied by default.
  • Page 25 DDNS DDNS (Dynamic Domain Name Service) is a service that allows a connection to an IP address using a hostname (URL) address instead of a numeric IP address. Most Internet Service Providers use Dynamic IP Addressing that frequently changes the public IP address of your internet connection; this means that when connecting to the camera over the internet, you need to know if your IP address has changed.
  • Page 26 After the configuration of FTP, you will be able to upload snapshots from network cameras to a specified FTP server. To configure FTP: 1. Type the Server IP address and Port Number. 2. Type the Username and Password for the upload account. 3.
  • Page 27 E-Mail After the configuration of E-mail, when alarms are triggered, you will be able to send messages to the specified E-mail address. The camera can send an e-mail via Simple Mail Transfer Protocol (SMTP) when a variety of events occur. SMTP is a protocol for sending e-mail messages between servers. SMTP is a relatively simple, text-based protocol, where one or more recipients of a message are specified and the message text is transferred.
  • Page 28 SNMP Settings With Simple Network Management Protocol (SNMP) enabled, the camera can be monitored and managed remotely with a network management system. Contact your network administrator if you are not familiar with SNMP setup. 36870AD...

  • Page 29: Streaming Settings

    STREAMING SETTINGS Video The Video settings menu configures the camera’s basic settings, including Frame Rate(fps), Bit Rate(Kbps), and the Image Quality. To configure the camera streams: Use the dropdown menus to configure the Video Compression, Frame Rate, Bitrate Type and Smart Encoding.
  • Page 30 Smart Encoding – The camera may be equipped with smart compression (H.264+), which drastically reduces the overall bit rate. Turn on Smart Encoding to enable H.264+ encoding to reduce bit rate. Frame Interval / GOP – The Group of Pictures setting allows you to modify the frame structure of the video stream.
  • Page 31 Audio Audio Input – Turn On to enable audio input devices. • Access Mode – Access Mode allows for line in or microphone in. • Input Gain - Sets the amplification that the camera applies to the incoming audio before transmitting. Designate a number between 0-255. •...
  • Page 32 When a ROI (Region of Interest) is added, the system ensures the image quality for the ROI first if the bit rate is insufficient. Eight Regions of Interest can be added or deleted, but only one can be selected. To set ROI: 1.
  • Page 33 Media Stream You can display the established media streams from a camera. You can also set the camera to transmit code streams by the UDP or TCP protocol to a specified IP address and port number. Note Changes to the media stream will take effect after the camera has been restarted. To configure media streams: 1.

  • Page 34: Picture Settings

    Use the Image section to modify picture settings for the camera. The sample image will change as you modify the picture settings. Note These settings can drastically affect the camera image. OpenEye suggests that these settings are only modified by a professional, or at the instruction or a technical support representative. Scenes Set up to five scenes with different image settings.
  • Page 35 Image Enhancement Each of the Image Enhancement settings is set to the recommended default. Use the sliders to change the settings. You may also type values directly. Brightness – Set the image’s brightness on the camera. The backlight value is adjustable from 0 (dim) ~ +255 (brightest).
  • Page 36 Day/Night Sensitivity – Light threshold for switching between day mode and night mode. A higher sensitivity means that the camera is more sensitive to the change of light and becomes more easily to switch between day mode and night mode. You can set this parameter only when Day/Night Mode is set to Automatic.
  • Page 37 • Sodium Lamp: The camera adjusts red and blue offset automatically according to the light condition (the color tends to be red). • Locked: Lock the current color temperature settings without adjustment. Red Offset – Adjust the red offset manually. You can set this parameter only when White Balance is set to Fine Tune.
  • Page 38 Display Style – • Effect: Change appearance of content displayed in view. • Font Size: Change size of content displayed in view. • Font Color: Click on the to change the color of the content displayed in view. • Min. Margin: Set a margin around content from the dropdown menu. •...

  • Page 39: Events Settings

    EVENTS SETTINGS Alarms Motion detection detects the object motion in a specified rectangular area during a period. You need to set a detection area, sensitivity of detection, object size, and history for the camera to decide whether to report a motion detection alarm when it detects motion. 1.

  • Page 40: Storage Settings

    STORAGE SETTINGS Storage Settings All OpenEye IP cameras include an integrated microSD™ card slot that can be used to record video or images. The card slot is compatible with a microSD™ card up to 128GB. Storage Medium, Storage Status and Total Capacity – Displays memory card information and allows you to Enable and Format card.

  • Page 41: Security Settings

    Recording Download Search a Recording Time range by clicking on the calendar dropdowns. Click the desired recording and Download. SECURITY SETTINGS User There are two types of users in the system: Administrator: The default name of the administrator is admin, which cannot be modified. Admin has full permission and can manage all users and devices.
  • Page 42 Note Only admin can change passwords. Changing the username or password for a user when the user is still logged in will force the user to log out. The user must use the new username or password to log in. Only admin can Add and Delete users.

  • Page 43: Maintenance

    Watermark You can set the video watermark for the camera to encrypt the video and protect it from being deleted or modified. Turn On Watermark and type the desired Watermark Content. MAINTENANCE Time On the Time page you can synchronize camera time with a system or a server as well as set Daylight Saving Time.
  • Page 44 Maintenance On the Maintenance page you can export the current configuration of the camera, or import the configuration for a camera. Use the factory default page to reset the IP Camera to factory default settings if necessary. Note Do not import configuration files from a different camera model. Software Upgrade Note Make sure the software upgrade file is available before starting the software upgrade.
  • Page 45 Device Restart Restart the camera Configuration Export Configuration: 1. Click Export under Export Files. 2. The .bin file will be saved. Note The default location for exported configurations is C:\ Upload (Import) Configuration: 1. Click Choose File in the Upload Files box. 2.

  • Page 46: Camera Specifications

    CAMERA SPECIFICATIONS Camera Model OE-C97512 Maximum Resolution 12MP (4000x3000) Image Sensor 1/1.7" progressive scan, CMOS Video Compression H.264 Enhanced, MJPEG 15 IPS @ H.264 12MP Fisheye Main Stream / 15 IPS @ H.264 3MP Fisheye Frame Rate Sub Stream / 25 IPS @ H.264 6MP Panorama / 15 IPS @ H.264 12MP...
  • Page 47 All rights reserved. No part of this publication may be reproduced by any means without written permission from OpenEye. The information in this publication is believed to be accurate in all respects. However, OpenEye cannot assume responsibility for any consequences resulting from the use thereof.
