System Alarms Map

Points Alarm Point
33 Default configuration
34 DCP poller inactive
SNMP community
39
error
41 Notification 1 failed
42 Notification 2 failed
43 Notification 3 failed
44 Notification 4 failed
45 Notification 5 failed
46 Notification 6 failed
47 Notification 7 failed
48 Notification 8 failed
49 NTP Failed
50 Call is in progress
51 Message is ready
52 Call is successful
No dial tone on the
53
line
54 Line is busy
55 Acked site
56 Timed Tick
Dynamic memory
57
full
58 Unit reset
61 TRIP error
62 Modem failed
Contact closure
63
comm failed
Description
Communication with Network Time Server has
failed.
The Site Dialer is configured to listen for DCP polls
but has not received a poll in over 5 minutes.
Community string does not match your SNMP
master's community string.
A notification 1 event, such as a page or email, was
unsuccessful.
A notification 2 event, such as a page or email, was
unsuccessful.
A notification 3 event, such as a page or email, was
unsuccessful.
A notification 4 event, such as a page or email, was
unsuccessful.
A notification 5 event, such as a page or email, was
unsuccessful.
A notification 6 event, such as a page or email, was
unsuccessful.
A notification 7 event, such as a page or email, was
unsuccessful.
A notification 8 event, such as a page or email, was
unsuccessful.
Communication with Network Time Server has
failed.
Notifies T/Mon that a call is in progress and to wait
before sending next notification.
Message has been received from T/Mon and is
ready to be sent.
Notifies T/Mon that call has completed successfully.
During dial-out attempt, the unit did not detect a dial
tone.
During dial-out attempt, the unit detected a busy
signal.
Notifies T/Mon to acknowledge an alarm.
Toggles state at constant rate as configured by the
Timed Tick timer variable. Useful in testing integrity
of SNMP trap alarm reporting.
Not expected to occur.
Unit has rebooted.
Not expected to occur.
The modem component to the Site Dialer has
stopped responding.
Not expected to occur.
Solution
Try pinging the Network Time Server's IP Address as
it is configured. If the ping test is successful, then
check the port setting and verify the port is not being
blocked on your network.
Check if unit can ping T/Mon or disable if not in use.
Verify both community strings to make sure they
match.
Use RPT filter debug to help diagnose notification
problems.
Use RPT filter debug to help diagnose notification
problems.
Use RPT filter debug to help diagnose notification
problems.
Use RPT filter debug to help diagnose notification
problems.
Use RPT filter debug to help diagnose notification
problems.
Use RPT filter debug to help diagnose notification
problems.
Use RPT filter debug to help diagnose notification
problems.
Use RPT filter debug to help diagnose notification
problems.
Try pinging the Network Time Server's IP Address as
it is configured. If the ping test is successful, then
check the port setting and verify the port is not being
blocked on your network.
Will be automatically cleared once call has been
completed.
Will be automatically cleared by T/Mon once call is
complete.
Will be automatically cleared by T/Mon once another
call is attempted.
Check the integrity of the phone line and cable.
Check the integrity of the phone line and cable.
Will be automatically cleared by T/Mon once another
call is attempted.
To turn the feature off, set the Timed Tick timer to 0.
Call DPS Tech Support (559) 454-1600
If unintentional, call DPS Tech Support: (559) 454-
1600.
Call DPS Tech Support (559) 454-1600
Check if modem is properly placed in socket. Contact
DPS Tech Support (559) 454-1600
Call DPS Tech Support (559) 454-1600
