SMART-AVI XTAV-TX User Manual

Technical Specifications

XP-AV SPECIFICATIONS
VGA Data
Format RGBHV, RGsB, YUV, Y/C, CVBS
Up to 1900 x 1200
Resolution
VGA, SVGA, XGA, SXGA)
Connector type HD 15 socket
Audio
Signal Type Stereo unbalanced
Connector 3.5mm jack socket
Power
Requirements 5VDC @.5A
Connector 2.1mm DC jack (center +ve)
Physical
Dimensions 135 x 90 x 23mm (26 with pegs)
Weight .8 lbs or .36 kg
