Raymarine ST290 Quick Reference Manual

ST290 Data Display - quick reference guide
Alarm pages enable you to set alarm modes & thresholds
You can use alarm pages to:
Set the operating mode of each Alarm, either OFF, ON or for operation with
an Auxilliary (external) alarm unit.
Set the threshold of each Alarm, to define when the Alarm will operate.
Note: Where examples are required, this guide uses the High Apparent Wind Angle Alarm. The principles are valid for all Alarms.
1. Enter the ALARMS chapter
ALARMS
SPEED
2. Select the Alarm page you want
SPEED
LOW
alarm
SPEED
LOW
alarm
TWS
HIGH
alarm
TWS
LOW
alarm
TWA
LOW
alarm
ST290 Data Display Alarm pages
How to see Alarm pages
KTS
HI SEA
LO SEA
TEMP
TEMP
alarm alarm
All Alarm pages display
Anchor Alarm pages also display
Note: This illustration shows the Alarm pages available in an
ST290 Full Profile. If a different profile is selected, some Alarm
pages may not be available.
TWA
HIGH
alarm
Note: This example shows how to see
FAVORITE pages in the upper display area.
The same principles are valid for the lower
display area.
SHALLOW
alarm
1 s
AWS AWS
LOW HIGH
alarm alarm
SHALL.
DEEP
ANCHOR
alarm
alarm
DEEP
ANCHOR
alarm
OFF
COURSE
alarm
AWA
HIGH
alarm
AWA
LOW
alarm
