ST290 Data Display - quick reference guide
Normal operation button actions
Hold down
for 1 second
Edit mode
Increase parameter value
Decrease parameter value
Press
Hold down for 1 second
Press
Hold down for 1 second
Press
Operation
Chapter Select mode
Lamp Adjust mode
Contrast Adjust mode
Select pages in current chapter
Select pages in current chapter
Set upper display as active display area.
Set lower display as active display area.
Setting an alarm: Press to set alarm
threshold, or switch alarm off.
Controlling a timer: Press to switch
timer on/off or start/stop timer.
Select
Press
chapter
Hold down
Select
1 second
chapter
Increase brightness
Decrease brightness
Hold down
1 second
Increase contrast
Decrease contrast
