ST290 Graphic Display - quick reference guide
Normal operation button actions
Hold down
for 1 second
Edit mode
Increase parameter value, or
select popup menu value
Decrease parameter value, or
select popup menu value
Press
Hold down for 1 second
Press
Hold down for 1 second
Press
Operation
Select pages in current chapter
Select pages in current chapter
Selecting a menu item:
Press when menu item is highlighted.
Setting an alarm: Press to set alarm
threshold, or switch alarm off.
Controlling a timer: Press to switch timer
on/off or start/stop timer.
Chapter Select mode
Press
Select
or
chapter
Press
Hold down
1 second
Select
or
chapter
Press
Lamp Adjust mode
Increase brightness
Decrease brightness
Hold down
1 second
Contrast Adjust mode
Increase contrast
Decrease contrast
