1 About this step switched machine

1.2.2 Control Program M201

PROGRAM M201
Comfortable Micro-processor control
„PROGRAM" M201
with one knob operation and 24 welding programmes for
a variety of welding applications which make work easier
for the user. The welder simply selects the type of
material and gas, the welding wire diameter and the
power range on the step switches and the machine is
already ready to weld. Tedious searching for the working
point is all done by the control. If the power range is set
too high or too low on the step switch - no problem! Signal
lamps show one should select a higher or lower range.
Further functions: Intelligent ignition management for
reliable and low splatter arc striking, automatic matching
of wire burn-back, wire input feed, gas pre- and post-flow
to suit the material selected; increased safety for both
machine and user due to automatic shut-down and short-
circuit recognition; steplessly adjustable wire feed rate
and wire feed compensation with arc-off feed-in of the
wire and gas test; Operating modes: 2- step (latch
on/latch off), 4 step (continuous welding), spot welding.
Options and accessories for use with the M201:
Wire compensation on the welding torch or on the remote
control, connections for MIG-Push/Pull torch with or
without wire feed correction potentiometer.
