EWM SATURN MIG 200 Operating Manual page 21

4 Description of the System components
4.3.1 Control "PROGRAM" M201
0
2
1
4
10
6
5
8
1
-10
m/min
2
3
4
5
6
7
Rotary knob for the stepless setting of:
2
4
6
15
•
8
Correction of the wire-feed speed
20
+10
•
Wire-feed speed 1 - 20 m/min
(Selector switch
Signal - Lamp:
Recommended change of switch setting if welding power selection too high
"Turn Step switch to the left" (or error message see 6.4)
Signal - Lamp:
Recommended change of switch setting if welding power selection too low
"Turn Step switch to the right" (or error message see 6.4)
Rotary knob for the stepless setting of:
• Spot welding time 0,1 - 4 Seconds
Changeover switch Operating Mode:
•
•
•
Selection switch for setting:
• Setting "manual": Two knob operation
• Welding wire diameter and type of material for Aluminium welding
• Welding wire diameter and type of material for welding Chrome-Nickel
Steels
Changeover switch for selecting type of gas
set to Manual position)
6
2- Step Mode,
4- Step Mode,
Spot Welding.
