EWM SATURN MIG 200 Operating Manual page 6

CONTENTS
8 Commissioning ...................................................................................................................... 8/1
8.1 Setting up the Welding Machine....................................................................................... 8/1
8.2 Mains Connection............................................................................................................. 8/1
8.2.1 Reconnecting the mains voltage 400/415V at the control transformer ................ 8/1
8.3 Cooling the Welding Machine........................................................................................... 8/2
8.4 Welding Torch Connections ............................................................................................. 8/2
8.4.1 MIG- Welding Torch ............................................................................................ 8/2
8.4.2 MIG- Welding Torch with adjustment knob for wire-feed correction
(Option, in preparation)........................................................................................ 8/2
8.4.3 Connection of MIG Push/Pull- Torch(Option) ...................................................... 8/3
8.5 Installing the Welding Wire ............................................................................................... 8/3
8.5.1 Insertion of the wire spool.................................................................................... 8/3
8.5.2 Inching the wire electrode ................................................................................... 8/4
8.5.3 Setting the spool brake ........................................................................................ 8/4
8.6 Workpiece Cable .............................................................................................................. 8/5
8.6.1 Changing the welding current polarity (option for cored wire welding) ................ 8/5
8.7 Shielding gas supply......................................................................................................... 8/6
8.7.1 Fitting the gas connections .................................................................................. 8/6
8.7.2 Shielding gas settings.......................................................................................... 8/6
9 Setting instructions ............................................................................................................... 8/6
10 Maintenance and Care......................................................................................................... 10/1
11 Operating Faults, Causes and Cures ................................................................................. 11/1
11.1 Customer Checklist ........................................................................................................ 11/1
12. Spare Parts List ................................................................................................................... 12/1
13. Accessories, Options (in preparation) ................................................................................ 13/1
14. Circuit diagrams .................................................................................................................. 14/1
Contents/4
