Triad CR Surround 2 Quick Start Manual

Surround 2 Speaker
Note: Correct
orientation
Grills
places tweeter &
horn beneath the
woofer.
CR Surround 2
Specifications:
loudspeaker designed for high performance
Sensitivity: 91dB @ 1 m 2.83 volts
Impedance: 4 ohm nom surround channel and certain house music
applications. A new type of surround
Power Handling: 200W
speaker, it combines the best characteristics
Rec Amp Power: 50W-400W
Max output: 114dB of conventional monopole, bipole & dipole
surround designs. Its ultra high output
F3 (-3dB): 50Hz
Rec Crossover: 80 Hz folded ribbon tweeter and proprietary Triad-
Dims: 22-1/16" w x 27.375" h x 9" d
designed wave guide enhance its horizontal
(560mm x 695mm x 222mm)
& vertical dispersion, creating a broad,
Weight: 55 lbs (25 kg)
smooth power response in a tailored hemi-
spherical polar pattern that fills rooms more
North American Limited Warranty
evenly than bipole & dipole surround de-
Triad speakers are warranted to be free from
signs, without their characteristic frequency
defects in manufacturing and workmanship (10)
response errors and volume variations.
years when operated under normal conditions.
Should any such defects occur within the
Timbre matched with our CR LCR 2,
warranty period call Triad Service at
Surround 2 delivers smooth transitions,
1-503-256-2600 for an RA number. Return
product in intact factory packaging with RA 3-dimensional surround soundstaging, and
number clearly visible on outside of box and
total immersion.
proof & date of purchase inside to:
Triad Speakers Inc., 15835 NE Cameron Blvd.,
Portland, Oregon 97230 USA
sound also works beautifully in house
Triad is not responsible for any shipping
music rooms that require high quality
damage coming in to Triad. If you do not have
sound evenly & broadly distributed
intact factory packaging, contact your dealer or
throughout a room.
Triad Service to purchase.
TriadSpeakers.com • Sales: 1800-666-6316
Speaker Parts
Endc ap
Top Bracket
w 3/8-20-2"
hex bolt
Enclosure
Bottom
Bracket
w 3/8-20-2"
hex bolt
Endcap
CR Surround 2 Applications for Home Theaters, Screening Rooms, and Gaming Rooms -
is a high output passive
surround channels and height & width effects channels. As side and back surround channels, they should be positioned with the speaker bottom a
minimum of 2 feet (61cm) above ear level and no closer than 1 foot (30.5cm) from the speaker top to the ceiling (Except for Atmos rooms. Please call).
They direct energy down to the listeners for enhanced focus and up to the ceiling for enhanced envelopment.
or swivel) mounting depth is 9-1/2 inches (241mm). At max tilt and swivel, depth is 14-1/2 inches (368mm). When mounting behind acoustically
transparent fabric walls, add min ¼" (6.5mm) clearance. Surround 2 can be flown or hung using the provided I bolts.
Horizontal Dispersion
Surround 2's room filling full-range
Triad CR Surround 2 & OnWall Bracket - Quick Start Guide
Included OnWall Bracket Parts
A
B
(1) Wall Bracket
(7) Wall Anchors
C
(7) #10 Oval
Philips Screws
D
(2) ¼-20 x 1" Allen
screws with (2) 1/4"
lock washers & (2)
1/4" flat washers
E
F
(1) 3/16" Allen
(2) 3/8" x 2-1/2"
Wrench
eyebolts
Standard OnWall Brackets give CR Surround 2 speakers up to 10 degrees downward tilt and 12 degrees lateral swivel adjustment. Minimum (no tilt
Side Views
CR Surround 2 Speaker
- Product Info & Warranty -
Additional Tools Needed
Screwgun with Socket wrench
Philips Bit with 9/16 inch
(14mm) socket
9/16" 14 mm
Pencil
3/8" (9.5mm)
drill bit for
Level
anchors
CR Surround 2 is ideal for side & back
Mounting Depths, Tilt, & Swivel
Max
Top Views
Tilt
Minimum Depth: No Tilt; No Swivel.
10deg
Max 10 degree Tilt; No Swivel.
Page 1
Ladder
Crew of 2
No Tilt; Max 12 degree Swivel.
Max Depth : Max 10 degree Tilt;
Max 12 degree Swivel.
2014.11.4
