- Page 1 AG 100-7 (S/D) AG 100-8 (S/D) AG 115-7 (S/D) AG 115-8 (S/D) English Printed: 23.07.2018 | Doc-Nr: PUB / 5169257 / 000 / 06...
- Page 2 Printed: 23.07.2018 | Doc-Nr: PUB / 5169257 / 000 / 06...
-
Page 3: Information About The Documentation
Information about the documentation About this documentation • Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free handling and use of the product. • Observe the safety instructions and warnings in this documentation and on the product. •... - Page 4 The type designation and serial number are printed on the rating plate. ▶ Write down the serial number in the table below. You will be required to state the product details when contacting Hilti Service or your local Hilti organization to inquire about the product. Product information...
- Page 5 Electrical safety ▶ Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. ▶ Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
- Page 6 Safety warnings common for grinding, sanding, wire brushing, polishing or abrasive cutting- off operations: ▶ This power tool is intended to function as a grinder or cut-off tool. Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
- Page 7 Kickback is the result of power tool misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below. ▶ Maintain a firm grip on the power tool and position your body and arm to allow you to resist kickback forces.
- Page 8 ▶ Grinding discs must be stored and handled carefully in accordance with the manufacturer’s instructions. ▶ Have the tool checked by Hilti Service after breakage of a disc, if the tool has been dropped or has fallen, or in the event of other mechanical damage.
- Page 9 English Printed: 23.07.2018 | Doc-Nr: PUB / 5169257 / 000 / 06...
- Page 10 English Printed: 23.07.2018 | Doc-Nr: PUB / 5169257 / 000 / 06...
- Page 11 Description Product overview English Printed: 23.07.2018 | Doc-Nr: PUB / 5169257 / 000 / 06...
- Page 12 Angle grinder, side handle, standard guard, front cover, clamping flange, clamping nut, wrench, operating instructions. Other system products approved for use with this product can be found at your local Hilti Store or online at: www.hilti.group | USA: www.hilti.com Restart interlock The product does not restart by itself when the on/off switch is locked in the ON position and power is restored after an interruption in the electric supply.
- Page 13 DC-EX 100/4" C dust hood for cutting or DC-EX 115/4,5" C compact hood (accessory) Use the compact hood when cutting masonry and concrete. CAUTION Use of this hood for working on metal is prohibited. Front cover for the disc guard When grinding with straight grinding discs and cutting with cutting discs in metalworking applications, use the standard guard with front cover.
-
Page 14: Technical Data
Rated speed 11,500 /min 11,500 /min 11,500 /min 11,500 /min Further information AG 100-7 S/D, AG 100-8 S/D AG 115-7 S/D, AG 115-8 S/D Maximum disc diameter 100 mm 115 mm Thread diameter Thread length 11 mm 15 mm Weight in accordance with 1.9 kg... -
Page 15: Before Use
Total vibration (vector sum of three directions) Other applications, such as cutting, may produce vibration values that deviate from the given values. Surface grinding with the vibration-absorbing side handle (a 6.5 m/s² h,AG Uncertainty (K) 1.5 m/s² Before use CAUTION Risk of injury. - Page 16 6.2.2 Adjusting the guard 1. Release the clamping lever. 2. Rotate the guard to the required position. 3. Secure the guard by closing the clamping lever. 6.2.3 Removing the hood 1. Release the clamping lever. 2. Rotate the guard until the keyed locating lug is aligned with the keyed locating groove and then remove the guard.
-
Page 17: Operation
6.3.1 Fitting an accessory tool 1. Disconnect the supply cord plug from the power outlet. 2. Clean the clamping flange. 3. Fit the clamping flange onto the drive spindle. 4. Fit the accessory tool. 5. Screw on the clamping nut corresponding to the type of accessory tool fitted. 6. -
Page 18: Care Of The Product
Switching on and off 7.2.1 Switching on (AG 1007S, AG 1008S, AG 1157S, AG 1158S) 1. Plug the supply cord into the power outlet. 2. Press the rear section of the on/off switch. 3. Slide the on/off switch forward. 4. Lock the on/off switch. ◁... -
Page 19: Transport And Storage
Most of the materials from which Hilti tools and appliances are manufactured can be recycled. The materials must be correctly separated before they can be recycled. In many countries, your old tools, machines or appliances can be returned to Hilti for recycling. Ask Hilti Service or your Hilti representative for further information. -
Page 20: Manufacturer's Warranty
Click on the links to go to the table of hazardous substances: qr.hilti.com/r2328143 (AG 100 S), qr.hilti.com/r2328115 (AG 100 D), qr.hilti.com/r2328145 (AG 115 S) and qr.hilti.com/r2328144 (AG115 D). You will find a link to the RoHS table, in the form of a QR code, at the end of this document. - Page 21 Printed: 23.07.2018 | Doc-Nr: PUB / 5169257 / 000 / 06...
- Page 22 Printed: 23.07.2018 | Doc-Nr: PUB / 5169257 / 000 / 06...
- Page 23 Printed: 23.07.2018 | Doc-Nr: PUB / 5169257 / 000 / 06...
- Page 24 Hilti = registered trademark of Hilti Corp., Schaan 20180711 Printed: 23.07.2018 | Doc-Nr: PUB / 5169257 / 000 / 06...
