Fluke P5510 User Manual

Pneumatic comparison test pump
Hide thumbs Also See for P5510:
Table of Contents

Advertisement

Quick Links

Download this manual
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
TestEquipmentDepot.com
P5510
Pneumatic Comparison Test Pump
Users Manual
PN 3952297
November 2010
© 2010 Fluke Corporation. All rights reserved. Printed in USA. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading

Related Manuals for Fluke P5510

Summary of Contents for Fluke P5510

  • Page 1 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 TestEquipmentDepot.com P5510 Pneumatic Comparison Test Pump Users Manual PN 3952297 November 2010 © 2010 Fluke Corporation. All rights reserved. Printed in USA. Specifications are subject to change without notice. All product names are trademarks of their respective companies.

  • Page 3: Table Of Contents

    Table of Contents Title Page Introduction......................1 Operating Ranges....................1 How to Contact Fluke ..................2 Safety Information ..................... 2 Safety Summary .................... 2 Compressed Gas .................... 2 Personal Protective Equipment..............2 Symbols Used in this Manual................ 2 Connections ....................... 3 Test Port Insert....................
  • Page 4 P5510 Users Manual...
  • Page 5 List of Tables Table Title Page Mode and Maximum Working Pressure ..............1 Symbols........................3 Test Port Insert - Parts List..................6 Handpump Assembly - Parts List................9...
  • Page 6 P5510 Users Manual...
  • Page 7 List of Figures Figure Title Page Fitting Gauge Adapter.................... 4 Connect Assembly to Test Port................4 Hand Tighten Only....................4 Adjust Gauge Position.................... 5 Tighten Gauge Adapter ..................5 Hand Tighten Only....................5 Handpump Assembly ..................... 9 Dirt/Moisture Trap ....................10 Angle Adapter ......................
  • Page 8 P5510 Users Manual...

  • Page 9: Introduction

    Four mounting holes are provided in the pump stand for this purpose. Operating Ranges Model P5510 combines the function of both pressure and vacuum pump with a selector valve that reverses the operating mode of the handpump. The table below details the mode and maximum working pressure of these instruments.

  • Page 10: How To Contact Fluke

    P5510 Users Manual Safety Information W Warning Read before Pneumatic Comparison Test Pump use. To prevent possible equipment damage or personal injury, follow these guidelines. Safety Summary The following are general safety precautions that are not related to any specific procedures and do not appear elsewhere in this publication.

  • Page 11: Connections

    Earth Ground Important Information: refer to manual Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information. Connections Fit the device under test (DUT) to the test port using the method described below:...
  • Page 12 P5510 Users Manual 1. Screw the appropriate gauge adapter fully on to the instrument to be tested. gla01.bmp Figure 1. Fitting Gauge Adapter 2. Screw assembly down COUNTER-CLOCKWISE on to test port. gla02.bmp Figure 2. Connect Assembly to Test Port gla03.bmp...
  • Page 13 Pneumatic Comparison Test Pump Connections Note Hand-tight is sufficient; ensure that the bottom face contacts the O-ring on the test port. 3. To adjust the position to face forward, hold the gauge adapter and turn the instrument COUNTER-CLOCKWISE, so that it faces forward. gla04.bmp Figure 4.

  • Page 14: Test Port Insert

    P5510 Users Manual Test Port Insert For devices with 1/8 BSP or NPT mounting threads, the diameter of the thread is very close to the effective sealing diameter of the O-ring fitted to the test port. This can make it difficult to achieve a good seal. When mounting these devices, use the test port insert (stored in the spare seals container) as shown in Figure 7.

  • Page 15: Pressure

    Pneumatic Comparison Test Pump Maintenance and Servicing 1. Ensure exhaust valve is closed — Do not over tighten, as damage to the valve seat can occur. 2. To generate a vacuum in the system, use the handpump until the desired reading is reached.

  • Page 16: Pump Disassembly

    P5510 Users Manual 2. Remove 4 screws from sides of the housing (2 each side), and lift out cover plate from underside. 3. Disconnect nylon tubing from check valves (23) and (19). 4. Loosen locknut (3) approximately 1 turn. 5. Remove spring clip (1) from clevis (2), and swing the pump handle out of the way.
  • Page 17 Pneumatic Comparison Test Pump Maintenance and Servicing 14 15 gla08.eps Figure 8. Handpump Assembly Table 4. Handpump Assembly - Parts List Item Description Part Item Description Part Spring Clip 3920224 Cylinder SPEC. Clevis 3920236 Bonded Seal 3918879 Locknut 3918713 O Ring 3865075 3918846 Set Screw...

  • Page 18: Ancillary Equipment

    P5510 Users Manual Ancillary Equipment Dirt/Moisture Trap, P5531 Dirt/Moisture Traps provide an effective barrier against the transfer of moisture and dirt from an instrument under test to the clean pneumatic system of the comparison test pump and the master test gauge connected to it. Unexpected particle contamination or fluid inside the device under test will be prevented from entering the test system, avoiding downtime for maintenance and repair.

  • Page 19: Pointer Remover/Punch, P5551

    Pneumatic Comparison Test Pump Ancillary Equipment Pointer Remover/Punch, P5551 To remove and refit the pointer of a pressure gauge, use a pointer remover/punch. This tool has a spring-loaded plunger to quickly and consistently refit the pointer. gla10.bmp Figure 11. Pointer Remover/Punch...
  • Page 20 P5510 Users Manual...
