P5513
Pneumatic Comparison Test Pump
Users Manual
PN 3963372
November 2010
© 2010 Fluke Corporation. All rights reserved. Printed in USA. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P5513-20M and is the answer not in the manual?

Questions and answers

Summary of Contents for Fluke P5513-20M

  • Page 1 P5513 Pneumatic Comparison Test Pump Users Manual PN 3963372 November 2010 © 2010 Fluke Corporation. All rights reserved. Printed in USA. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
  • Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
  • Page 3: Table Of Contents

    Table of Contents Title Page Introduction......................1 How to Contact Fluke ..................1 Safety Information ..................... 1 Safety Summary .................... 1 Compressed Gas .................... 2 Personal Protective Equipment..............2 Symbols Used in this Manual ................2 Preparation ......................2 Operating Range ....................2 Connections .......................
  • Page 4 P5513 Users Manual...
  • Page 5: List Of Tables

    List of Tables Table Title Page Symbols........................2 Test Port Insert - Parts List..................6 Screw Press Assembly - Parts List................. 9...
  • Page 6 P5513 Users Manual...
  • Page 7: List Of Figures

    List of Figures Figure Title Page Fitting Gauge Adapter.................... 3 Connect Assembly to Test Port................4 Hand Tighten Only....................4 Adjust Gauge Position.................... 5 Tighten Gauge Adapter ..................5 Hand Tighten Only....................5 Test Port Insert ....................... 6 Screw Press Assembly ................... 8 Angle Adapter ......................
  • Page 8 P5513 Users Manual...
  • Page 9: Introduction

    Primary Reference Standard (such as a Deadweight Tester) to ensure accuracy is maintained. How to Contact Fluke To order accessories, receive operating assistance, or get the location of the nearest Fluke distributor or Service Center, call: •...
  • Page 10: Compressed Gas

    AC (Alternating Current) Earth Ground Important Information: refer to manual Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information. Preparation The comparison test pump should be placed on a stable workbench or similar surface.
  • Page 11: Connections

    Pneumatic Comparison Test Pump Connections Connections Fit the device under test (DUT) to the test port using the method described below: W Caution Ensure that all devices are internally clean and free from contamination before connecting to the tester. Particle contamination can damage the sensitive piston assemblies, valve seats and screw pump.
  • Page 12 P5513 Users Manual 2. Screw assembly down COUNTER-CLOCKWISE on to test port. gmf02.bmp Figure 2. Connect Assembly to Test Port gmf03.bmp Figure 3. Hand Tighten Only Note Hand-tight is sufficient; ensure that the bottom face contacts the O-ring on the test port. 3.
  • Page 13 Pneumatic Comparison Test Pump Connections gmf04.bmp Figure 4. Adjust Gauge Position 4. Hold the instrument steady, while turning the gauge adapter COUNTER-CLOCKWISE until it pulls down onto the O-ring. gmf05.bmp Figure 5. Tighten Gauge Adapter gmf06.bmp Figure 6. Hand Tighten Only...
  • Page 14: Test Port Insert

    P5513 Users Manual Test Port Insert For devices with 1/8 BSP or NPT mounting threads, the diameter of the thread is very close to the effective sealing diameter of the O-ring fitted to the test port. This can make it difficult to achieve a good seal. When mounting these devices, use the test port insert (stored in the spare seals container) as shown in Figure 7.
  • Page 15: Maintenance And Servicing

    Pneumatic Comparison Test Pump Maintenance and Servicing Note Large, sudden changes in pressure will cause the system temperature to rise or fall, which can cause instrument readings to change as the gas in the system expands or contracts, thus increasing or decreasing the pressure. 4.
  • Page 16 P5513 Users Manual 7. If it is necessary to remove the barrel, the locknut (3) must be loosened approximately ½ turn. The barrel can then be unscrewed from the test station (1). Note It is often easier to remove the barrel support bracket to allow greater movement, (remove the 2 screws from the upper side of the top plate).
  • Page 17: Ancillary Equipment

    Pneumatic Comparison Test Pump Ancillary Equipment Table 3. Screw Press Assembly - Parts List Item Description Part TEST STATION 3921414 O RING 3864922 LOCKNUT 3921438 BARREL 3921450 SUPPORT BRACKET 3921492 O RING 3867566 ANTI-EXTRUSION RING 3919118 RAMBLER 3919129 BALL 3917855 LEAD SCREW ASSY 3885994 Ancillary Equipment...
  • Page 18: Pointer Remover/Punch, P5551

    P5513 Users Manual Pointer Remover/Punch, P5551 To remove and refit the pointer of a pressure gauge, use this tool. This tool has a spring-loaded plunger to quickly and consistently refit the pointer. gmf10.bmp Figure 10. Pointer Remover/Punch Dirt/Moisture Trap, P5532 Dirt/Moisture Traps provide an effective barrier against the transfer of moisture and dirt from an instrument under test to the clean pneumatic system of the comparison test pump and the master test gauge connected to it.
