Jacto PJH Operator's Manual

STATEMENT OF LIMITED WARRANTY
MÁQUINAS AGRÍCOLAS JACTO S.A. shall warrant the equipment described
in this manual and shall repair or replace parts and components which, under normal
operation and wear, in accordance with technical recommendations, show DEFECTS
IN MATERIAL OR WORKMANSHIP, based on the following conditions.
WARRANTY PERIOD
- 03 (three) years from the date of sale to the original purchaser.
WARRANTY APPLICATION
- JACTO shall honour this warranty, free of charge, if any part or component shows defect
in MATERIAL OR WORKMANSHIP, after final analysis at the factory.
THIS WARRANTY SHALL BE NULL & VOID IN CASE OF:
- Misuse of the equipment against specifications in the OPERATOR'S MANUAL, overwork
or accidents.
- Preventive/remedial maintenance performed by unauthorized people.
- Use of parts and components not supplied by JACTO.
- Modification of the equipment or any characteristic of the original design.
THIS WARRANTY SHALL EXCLUDE:
- Parts which show wear and tear due to use, UNLESS THEY SHOW DEFECTS IN
WORKMANSHIP, ASSEMBLY OR MATERIAL.
- Damages resulting from accidents.
- Transportation or freight of the equipment, parts and components in case such warranty
is not approved.
- Transportation and mobilization of technicians.
GENERAL INFORMATION:
- Parts replaced within the warranty period shall be property of JACTO.
- The warranty on replaced parts and components shall expire together with the equip-
ment warranty period.
- Eventual delays in performing services shall not give the owner right either to indemnity
or to extension of the warranty period.
- JACTO reserves the right to modify its products or to interrupt the manufacture without prior
notice.
MÁQUINAS AGRÍCOLAS JACTO S.A.
Rua Dr. Luiz Miranda, 1650
17580-000 - Pompéia - SP - Brasil
Tel.: +55 14 3405-2100 - Fax: +55 14 3452-1306
E-mail: export@jacto.com.br
Home page: www.jacto.com.br
05/2014 - 120543 - 0004-MI
OPERATOR'S MANUAL
PJH

1- INTRODUCTION

This manual contains information for the proper assembly, operation and care of
your sprayer.
Carefully read and follow the instructions contained in this manual before using
your sprayer.

2- SPRAYER VIEW

Lid
Chamber
Rod
Lever
Nozzle

3- SPECIFICATIONS

Model ......................... PJH
Net weight.................. 5,0 kg
Tank
- Capacity .................. 20 liters
- Material .................... Polyethylene
- Fill opening diameter 140 mm
Diaphragm
Tank
Hose
Trigger valve
Lance
Pump
- Type .........................................Piston
- Material ....................................Polyamide
- Working pressure (max.) .........6 kgf/cm²
Lance length ..............................600 mm
Hose length ...............................1,350 mm
Nozzle fitted ...............................JD-12P
