Toa ST-800 Instruction Manual

MICROPHONE STAND
Thank you for purchasing TOA's Microphone Stand.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

1. SAFETY PRECAUTIONS

CAUTION
Indicates a potentially hazardous situation which,
if mishandled, could result in moderate or minor
personal injury, and/or property damage.
• Avoid installing or mounting the unit in unstable
locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling
down and causing personal injury and/or property
damage.
• Do not lay the connection cable where it can be
walked on or tripped over, causing personal injury.

2. GENERAL DESCRIPTION

The ST-800 is a desk-top microphone stand base
designed for use with a gooseneck condenser microphone.
It features compact and stable design.

3. HANDLING PRECAUTIONS

To clean, be sure to first disconnect the connection cable,
then wipe with a dry cloth. When the unit gets very dirty,
use a cloth damped in a neutral cleanser. Never use
benzene, thinner, alcohol, or chemically-treated cleaning
cloth because such volatile liquids could deform or discolor
the unit.
Manufacturer:
TOA Corporation
7-2-1, Minatojima Nakamachi, Chuo-ku, Kobe, Hyogo, Japan
Traceability Information for Europe (EMC directive 2004/108/EC)
日本語の取扱説明書は裏面をご覧ください。
INSTRUCTION MANUAL

4. CIRCUIT DIAGRAM

Input
1
2
Shield Hot
3
Cold
5. APPEARANSE
124 (4.88)
Unit: mm (in)
Weight: 715 g (1.58 lb)
Finish (Main body): Die-cast zinc, black, paint, mat
Authorized representative:
TOA Electronics Europe GmbH
Suederstrasse 282, 20537 Hamburg, Germany
ST-800
Output
1
2
Shield Hot
3
Cold
Body earth
To remove the microphone,
press this locking button.
Input connector
(XLR-3-31 or equivalent)
Output connector
(XLR-3-32 or equivalent)
