HORN MOUNTING BRACKET
General Description
The HY-940 horn mounting bracket is designed exclusively for mounting the TOA LE-940 constant
directivity horn onto the SB-38W low frequency, vented (bass-reflex) enclosure when the standard speaker
system (GS-3806W) is configured.
Parts List
Bracket
No. 1
1
Bracket
No. 2
1
Bracket
No. 3
1
Bracket
No. 4
1
Bracket
No. 5
1
Supplied Accessories :
1. Hex. bolt (M8 x 20)
2. Hex. bolt (M8 x 30)
3. Hex. nut (M8)
4. Flat washer (W8)
5. Spring lock washer (SW8) 13
Handling Precautions
The HY-940 is designed exclusively for system configuration of the standard speaker system GS-3806W,
and do not use for other than this application.
TOA takes no responsibility for accidents or injuries caused by faulty mounting methods or poorly selected
mounting locations.
4
9
2
15
Instruction Manual
Figure 1
HY-940
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Toa HY-940
Summary of Contents for Toa HY-940
-
Page 1: Parts List
The HY-940 is designed exclusively for system configuration of the standard speaker system GS-3806W, and do not use for other than this application. TOA takes no responsibility for accidents or injuries caused by faulty mounting methods or poorly selected mounting locations. - Page 2 As shown in Figure 3, the horn mounting angle can be adjusted 10° up or down from horizontal in 5° steps. This mounting example shows that the horn mounting angle is adjusted 5° down from horizontal. Figure 3 TOA Corporation KOBE, JAPAN 133-01-336-60...
- Page 3 HY-940 * Please see the reverse side for English manual.
