The HY-PF1B is used exclusively to suspend the HX-5 speaker system from the ceiling. The FB-120 series Sub-
woofer can be suspended using this frame and the frame's supplied mounting brackets. This bracket is designed
for indoor use.
Specifications
Dimensions (W x H x D)
Dimensions (ø x D)
Finish
We supply sound,
not equipment.
www.toa.eu.
550 x 50 x 512 mm
x 512 mm
Steel plate, semi-gloss, paint, black
SPEAKER RIGGING FRAME
©TOA Electronics Europe GmbH | Data subject to change without notice.
HX-5 Series
HY-PF1B
Order no: HY-PF1B EU
EN, 2020/07/26
Advertisement
Table of Contents
Related Manuals for Toa HY-PF1B
Summary of Contents for Toa HY-PF1B
- Page 1 HY-PF1B SPEAKER RIGGING FRAME The HY-PF1B is used exclusively to suspend the HX-5 speaker system from the ceiling. The FB-120 series Sub- woofer can be suspended using this frame and the frame's supplied mounting brackets. This bracket is designed for indoor use.
- Page 2 Hanging the FB-120B Holes B are used for hanging between the HY-PF1B and the ceiling (4-point hanging). Subwoofer mounting bracket (accessory) 3-27 25 We supply sound, not equipment. ©TOA Electronics Europe GmbH | Data subject to change without notice. www.toa.eu. EN, 2020/07/26...
