FLUSH CEILING
MOUNTING BRACKET
Thank you for purchasing TOA flush ceiling
mounting bracket.
Please carefully follow the instructions in this
manual to ensure long, trouble-free use of your
equipment.
1. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe
operation.
• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/ or
cautions regarding safety.
• Keep this instructions handy for future reference.
WARNING
• Avoid installing the unit in unstable locations, such as on a rickety or slanted surface. Failure to do so may
result in the unit falling and possibly causing personal injury.
• Install the unit only in a location that can structurally support the weight of the unit and the mounting bracket.
Doing otherwise may result in the unit falling down and causing personal injury and/ or property damage.
• Do not use the bracket for mounting any camera other than the combination camera. Failure to follow this
instruction could cause the camera to fall and result in personal injury.
• Ensure that all screws and fixing mechanism are securely tightened. If they are not tightened or firmly
secured after installation, the unit could fall down, possibly resulting in personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
INSTALLATION MANUAL
C-BC511U
C-BC511U-S
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Toa C-BC511U
Summary of Contents for Toa C-BC511U
-
Page 1: Installation Manual
INSTALLATION MANUAL FLUSH CEILING C-BC511U MOUNTING BRACKET C-BC511U-S Thank you for purchasing TOA flush ceiling mounting bracket. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment. 1. SAFETY PRECAUTIONS • Before installation or use, be sure to carefully read all the instructions in this section for correct and safe operation. - Page 2 • To avoid electric shock, be sure to switch off the power before power supply wiring work. • Leave the installation of the unit to your TOA dealer because the installation requires expert experience and skills. Incorrect installation may cause an electric shock or personal injury.
-
Page 3: General Description
C-BC511U ( transparent dome version ) and C-BC511U-S ( smoked dome version ) . Since camera orientation cannot be seen from outside the enclosure when the C-BC511U-S is used, it is more effective in enhancing the effect of surveillance. - Page 4 1.2 kg Applicable camera C-CC514, C-CC564 * When using the C-BC511U-S, the subject's illumination must at least be 5 times brighter than when using the C-BC511C. Note: The design and specifications are subject to change without notice for improvement. • Accessories Safety wire ..........
