Toa C-BC511A Installation Manual

Ceiling mounting bracket

CEILING MOUNTING

BRACKET

Thank you for purchasing TOA ceiling mounting

bracket.

Please carefully follow the instructions in this

manual to ensure long, trouble-free use of your

equipment

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe

operation.

• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/ or

cautions regarding safety.

• Keep this instructions handy for future reference.

WARNING

• Install the unit only in a location that can structurally support the weight of the unit and the mounting bracket.

Doing otherwise may result in the unit falling down and causing personal injury and/ or property damage.

• Do not use the anchor bracket for mounting any camera other than the combination camera. Failure to follow

this instruction could cause the camera to fall and result in personal injury.

• Ensure that all screws and fixing mechanism are securely tightened. If they are not tightened or firmly

secured after installation, the unit could fall down, possibly resulting in personal injury.

Indicates a potentially hazardous situation which, if mishandled, could

result in death or serious personal injury.

INSTALLATION MANUAL

C-BC511A

Table of Contents

Do you have a question about the C-BC511A and is the answer not in the manual?

Page 1: Installation Manual
INSTALLATION MANUAL CEILING MOUNTING C-BC511A BRACKET Thank you for purchasing TOA ceiling mounting bracket. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment 1. SAFETY PRECAUTIONS • Before installation or use, be sure to carefully read all the instructions in this section for correct and safe operation.
Page 2 When Installing the Unit • Leave the installation of the unit to your TOA dealer because the installation requires expert experience and skills. Incorrect installation may cause an electric shock or personal injury.
Page 3: General Description
2. GENERAL DESCRIPTION The C-BC511A Ceiling Mounting Bracket is designed to be used for mounting the C-CC514 or C-CC564 Combination Camera to a ceiling directly. By using this mounting bracket in conjunction with the C-BC511C or C-BC511C-S Ceiling Mounting Cover, cameras can be mounted to gypsum board ceilings or other weak ceiling panel materials in which mounting screws cannot be securely inserted.
Page 4: Specifications
2. Attach the base unit to the ceiling mounting bracket. Ceiling Note Use the supplied camera mounting C-BC511A screws when attaching the base unit to Safety wire Celing Mounting (supplied with the the ceiling mounting bracket.
