Operation; Main Menu; System Information - GeoMax Zoom90 User Manual

4
4.1
Description

MAIN MENU

4.2
Description
Access
SYSINFO

System information

Operation

Operation
Main Menu
The MAIN MENU is the starting place for accessing most functionality of the instrument. It is displayed
when selecting the Zoom90 basic application from the WinCE main screen.
Description of the MAIN MENU functions
Function Description
1 Level To select and open Level Up screen. Refer to " Level up with the electronic level step-
by-step".
2 Sysinfo To select and start Sysinfo. Refer to "4.2 System Information".
3 Settings To select and start Settings. Refer to "5 Settings".
4 Apps To select and start Apps. Refer to Apps
System Information
The SYSINFO screen display instrument, system and firmware information, as well as date and time.
Select Sysinfo from the MAIN MENU.
This screen displays information about the instrument and operating system.
Page 1
Field
Instrument Model
Serial Number
Equipment Number
Angle Accuracy
EDM
Page 2
Page 2 displays several version numbers of software and hardware components.
LEGAL
To display legal info according open source soft-
ware.
Description
Displays the type name of the instrument.
Displays the serial number of instrument.
Displays the equipment number of instrument.
Displays the accuracy of angle measurement.
Displays the type of EDM.
Zoom90 | 24
