Summary of Contents for GeoMax ZOOM 10

  • Page 2 Total Station Manual Preface Thanks a lot for purchasing our total station! This manual is your good helper, please read it carefully before using the instrumentand keep it safely. Product affirms: In order to get the best service from our company, please feedback your instruments’ versionincludingnumber, purchasing date and your suggestions to us after the purchasing of the product.
  • Page 3 3. No prism ranging The series Total Station ZOOM 10 with laser ranging No-Prism is capable of surveying forlong distance, fast and precise measurements with various materials and different colors of objects (such as building walls, poles, wires, cliff wall, mountain, mud , stakes, etc.).
  • Page 4 11. Theemitted light of the no-prism total station ZOOM 10 is laser, do not direct to eyes. The elements of the instructional safeguard shall be as follows: –...
  • Page 5 Total Station Manual Security Guide Pay attention to the following safety matters when you use the laser ranging free of prism. Warning: Total station fit out laser level 3R/ a which is recognized by the loge, which is above: the verticallocking screw saying “3A laser product ”.This product belongs to Class 3R levellaser .According to the following standards IEC 60825-1 2001Class 3R/...
  • Page 6 Total Station Manual Harmful Distance is the maximum distance from the starting point of the laser beams to where people are right safe.The built-in harmful idstance of the Class 3R/ a laser is 1000m(3300ft) and the laser intensity will reduce to that of Class 1 products (which does not harm eyes) if people is out of this range.
  • Page 7 Total Station Manual Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

  • Page 8: Table Of Contents

    Total Station Manual CONTENTS 1. Name and function of eachpart................11 1. Name......................11 2. Keys Functions and information display............13 2. Preparation before measurement................14 1. Unpack and store instrument................14 2. Setting up the instrument................14 3. About the battery....................16 4. Reflecting prism..................... 17 5.
  • Page 9 Total Station Manual 3. NP/P Toggle....................47 4. Height Transfer....................47 5. Hidden Point....................51 6. Free Coding....................53 7. Laser Pointer....................53 8. Light....................... 53 9. Unit Setting....................53 Main Setting.................... 54 EDM Tracking..................55 5. Applications......................56 1. Setting the Job....................56 Create a new Job................56 Select anExisting Job from Memory..........58 2.
  • Page 10 Total Station Manual 11.2 Inverse.................... 110 11.3 Bearing-Bearing Intersection............113 11.4 Bearing-Distance Intersection............115 11.5 Distance-Distance Intersection............118 11.6 Line-Line Intersection..............121 11.7 Distance-Offset................123 11.8 Set Point..................124 11.9 Extension..................127 Road...................... 129 12.1 Road Manage................. 129 12.2 Horizontal curve definition............130 12.3 Vertical curve definition..............
  • Page 11 Total Station Manual 2. EDM Setting....................189 9. Adjust and Tools....................190 1. Adjust......................190 View adjust parameters..............190 Adjust Index Error................191 Adjust Tilt X...................191 Adjust Tilt Y...................193 Instrument constant setting............195 Factory setting................195 2. System infomation..................196 View System Information.............. 196 Set System Date................

  • Page 12: Name And Function Of Eachpart

    Total Station Manual 1. Name and function of eachpart 1. Name...
  • Page 13 Total Station Manual...

  • Page 14: Keys Functions And Information Display

    Total Station Manual 2. Keys Functions and information display Function Power ON/ Power OFF. MEAS Trigger key, depends on setting, maybe disting& save, disting or none. Cancel or exit. Confirm or commit editing. Switch pages Hot key to enter function menu in measuring interface. User defined function key 1.

  • Page 15: Preparation Before Measurement

    Total Station Manual 2. Preparation before measurement Unpack and store instrument Unpack Put down the box gently and turn up the cover then turn on the lock, open the cover and take out the instrument. Deposit Cover up the telescope mirror and make the vertical motion of alidade upwards then put the instrument horizontally (keep the objective upwards) into box.
  • Page 16 Total Station Manual Rotate instrument 90°by vertical axis, then use foot screw C to center the bubble. Repeatsteps above until the bubble is at the same place in all directions. 2. Centering by centering tool ( optional or laser ) 1) Set up a tripod Extend a tripod to the appropriate height make sure the legs are spaced at equal intervals and the head is approximately level .Set the tripod so that the head is...

  • Page 17: About The Battery

    Total Station Manual aim at station accurately. Tighten the center connection screw and leveling instrument accurately again. This operation should be repeated till the plumb aims at station accurately. 3. About the battery Mounting the battery Fully charge the battery before measurement. Cut off the power before removing the battery.

  • Page 18: Reflecting Prism

    Total Station Manual completely. Charge the battery once a month no matter if it is used to prolong its longevity. 4. Reflecting prism When using a prism mode for measuring distance, reflection prism should be placed where the target is. A reflecting prism group includes one or three prisms that can connect prism group placed at the base of the tripod with the dock connector or by placing them in the stem directly.

  • Page 19: Input Characters

    Total Station Manual Number input box: In number input box, user can only input numbers, include “1-9”,“.”, “-+”. Number will appear in box when user presses the key. Text input box: In text input box, user can input numbers and letters. Repeat pressing same key to get proper letter, such as A->B->C->7.

  • Page 20: Delete Characters

    Total Station Manual 2 Press key 1, key 2, key 3. Then press key F4, [1],[2],[3],[F4 active text input mode.Icon should appear in right bottom screen. 3 Press key 7, display letter ‘A’, wait about half second, press key 7 twice, display letter ‘B’, then [A],[B],[V],[ press key 2, display letter...

  • Page 21: Point Search

    Total Station Manual [F1] 2 Press key F1(Delete). 3 Press key ENT to confirm [ENT] input. Press Key ESC to [ESC] undo changes. 8. Point Search Point search is a function used by applications to find measured or fixed points in the jobs.
  • Page 22 Total Station Manual searching result window, using arrow key [F4] to move cursor to select [ENT] point number. Press key F4 or ENT to conirm selecting. Soft keys introduction: [View] Show the coordinate of selected point. 3 Using arrow key move cursor and select point [F1] number.
  • Page 23 Total Station Manual 4 Input point number and N, E, Z values, by pressing ENT [ENT] to move cursor to next input box. 5 After all values finishing [F4] input, pressing key F4 to save the point to the job. [Job]Choose another job’s points.

  • Page 24: Wildcard Search

    Total Station Manual 6 Press key F4 to search the [F4] point in the selected job. [F2](Zero): Set N, E, Z to 0. [F3](Coord.): Input point manually. [OK] Commit selected point. 8.2 Wildcard search The wildcard search is indicated by a “*”. The asterisk is a place holder for any following sequence of characters.

  • Page 25: Q-Survey

    Total Station Manual 3. Q-Survey 1. Notes in the distance measurement After the placement of instrumentand turned on the power, total station is ready, can start measuring. In measurement display, user can call the function of set key, the functionkeys and hotkey. The show is an example.
  • Page 26 Total Station Manual When start the distance measurement, EDM will measure distance for the object in the light path.If there are temporary obstacles in the light path (such as by car, or the heavy rain, snow, or filled with fog), the distance measured by EDM is the distance to the nearest obstacle.

  • Page 27: Edm Setting

    Total Station Manual 2. EDM Setting 2.1 Set the mode of EDM Select mode distance measurement,there modes Single,Repeat,Tracking,3 Times,4 Times,5 Times. Steps Display 1 Press [F4]( )and show the second soft key in the [F4] Q-Surveying. Press [F3] to [F3] enter the interface of EDM Setting.
  • Page 28 Total Station Manual refer to “Technical Parameters”. Steps Display After entering to the interface Setting,using the direction of to move the cursor to the setting item of Reflector. 2 Press to select the types of reflector. Each time you press , the type of reflector is switched.

  • Page 29: Atomosphere Setting

    Total Station Manual Steps Display After entering to the interface Setting,using the direction of to move the cursor to the setting item of P.C. 2 Enter the prism constant [ENT] value and press the key of [ENT]. After finished setting, press [F3](OK) to return the function Q-Surveying.If...
  • Page 30 Total Station Manual Steps Display After entering to the interface of EDM Setting, [F1] press [F1] (Atoms) to enter the interface of Atomspheric Data. Interface displays current setting, using direction of to move the cursor to the setting item of Refraction.
  • Page 31 Total Station Manual If the air pressure unit is mmHg, Make a conversion according to the formula: 1hPa=0.75mm Hg Standard meteorological conditions (atmospheric correction value =0 ): press: 1013hPa temperature: 20 If the atmospheric correction is not required, please set PPM to zero. Steps Display After entering to the...

  • Page 32: Grid Factor Setting

    Total Station Manual item of PPM. After finishing setting, press [F4](OK) to save settins back previous [F4] menu.Then press the key of [F3] [F3](OK) to save the setting of EDM and back to the function of measurement. 1: The range of enter: Temp.(-30 60 ), Press.(500hPa 1400hPa).
  • Page 33 Total Station Manual HD: Ground distance 2. Ground distance HD=HDg/(Grid factor) Note: 1. The enter range of the scale factor: 0.99~1.01,the default value is 1.0. 2. The enter range of the average height above sea level: -9999.9999~9999.9999. The average altitude retained after the decimal point one, the default value is 0. Steps Display After entering to the...

  • Page 34: Edm Signal

    Total Station Manual 2.4 EDM signal The function of signal is to display the intensity of signal received by total station.If the target is hard to be found or can’t see, using the function can achieve the best sighting accuracy. Steps Display After entering to the...

  • Page 35: Start Measurement

    Total Station Manual 3. Start measurement Q-Survey has 3 pages menu, including all measuring functions commonly used, such as angle measurement, distance measurement and coordinate measurement. As shown below: 3.1 Set HA You can set the horizontal angle as 0 or set it as wanted angle. Set horizontal angle to 0.
  • Page 36 Total Station Manual Press [F2](Zero), [F2] screen give a prompt to set HA as 0 or not. 3 Press [F4](Yes), the screen [F4] backs to Q-Survey and HA is set as 0. If you want to cancel [F1] the operation,please press [F1](No).
  • Page 37 Total Station Manual [ESC] to go back. If want other value of angle as the orientation angle,you need to enter the wanted value of [F4] B: Input angle angle and press [ENT], then press [F4](OK). Example: enter 121.2030 (121 20 30 ). C: [Zero] If want to set HA to 0,press [F1]...

  • Page 38: Set Station And Instrument Height

    Total Station Manual 3.2 Set Station and instrument height After set the coordinate of station (the site of instrument) relatives to the origin, the instrument can calculate the coordinate of the location to your position (the site of prism). You can set station and the instrument height conveniently in the Q-Survey. Steps Display [F4]...

  • Page 39: Measurement

    Total Station Manual 3.3 Measurement After all settings have been finished, you can start to measure. There are 3 pages to display the result of measurement, including all measurement data and you can press [PAGE] to view. Steps Display 1 Input the name of point and instrument height.Move [ENT] the cursor to the next edit text...

  • Page 40: Code

    Total Station Manual 3.4 Code The code contains the information about the recording points, in the process of post-processing, with the help of encoding function , you can process conveniently according to the specific group.The function of “File Manager” also contains the information of code.
  • Page 41 Total Station Manual Before REC: Record code data before recording the actual measurement data. After REC: Record code data following after the actual measurement data. Soft key of Code After starting the function of soft key (Code), Screen displays the following: GSI-the introduction of code properties: Code: The name of code Note: The additional note...

  • Page 42: Funtions

    Total Station Manual 4. Funtions Bring the total station’s common functions and settings together, they can be used in the process of measurement conveniently. In the function of Q-Survey which in the Main menu or other interface of measuremen in the program,you can press [FNC] to enter the menu of Function The menu of Function has 4 pages, you can press PAGE...

  • Page 43: Offset

    Total Station Manual station. Press [On] to open the compensator and press [Off] to close the compensator. Press [X Only] to open the compensator of X direction. Press [ ][ ] to adjust the laser plummet brightness. Press [OK] to closs the laser plummet and exit. 2.

  • Page 44: Cylinder Offset

    Total Station Manual program Q-Survey, press [FNC] to [F2] open the menu of Function, next pressing [F2] to enter the program of Offset. Input the values of Trav.OFS, LengthOFS and [F4] HeightOFS, then select the mode of offset and press [F4] to save.
  • Page 45 Total Station Manual between cylinder and station. Steps Display program Q-Survey, press [FNC] to [F2] enter the menu of Function, then pressing [F2] to enter the program of Offset. 2 Press [F2] to enter the [F2] subprogram Cylinder Offset. 3 Aim at the left edge of cylinder, press [F1] to make sure the angel of Hz Left, [F1]+[F2...

  • Page 46: Angel Offset

    Total Station Manual Display the result of cylinder offset. 2.3 Angel Offset Angle Offset is used to measure the points which are intervisible but hava no reflector and can’t set up the prism. The basic principle is making the target point and measurement point in the concentric circles whose center is station point, then measuren the position information of station point and measurement point and the angle offset of station to target point, thus can calculate the coordinate of target point.
  • Page 47 Total Station Manual Press [F3] to enter the [F3] subprogram of Angel Offset. 3 Aim at the measurement [F1] point and press [F1] to measure distance. 4 Aim at the target point and press [F4] to make sure the direction of target point, [F4] next enter the program that displaying the result of angle...

  • Page 48: Np/P Toggle

    Total Station Manual 3. NP/P Toggle Switch the mode of reflector quickly. (P is the mode of Prism and NP is the mode of Non-Prism) Open the first page of Function Menu and press [F3] to switch the mode of reflector. 4.
  • Page 49 Total Station Manual Steps Display 1 Press [F4] or [4] in the [F4] first page of [Function] to enter the function of Height Transfer measurement. Press [F4] twice and [F4] display the third page of soft keys, press [F2](IH)to [F4] enter the function of setting instrument height, inputing [F2]...
  • Page 50 Total Station Manual 3 Selcet the fixpoint and input the height of Prism. The numbers of measured fixpoints are displayed in the top right corner. [F4] There are 3 methods to selecting fixpoint. [F2] A: [List] A: Press [F4] to enter the second page of soft key [F4] and press [F2](List) .In...
  • Page 51 Total Station Manual 4 After finishing setting up the fixpoint, the height [F1] of fixpoint is displayed in screen press [F2] [F1](ALL)or [F2](DIST)+[F3](REC) to [F3] start measure calculate, the height of station is calculated. In the interface of [Height Transfer Result], pressing [PAGE] to switch display result...

  • Page 52: Hidden Point

    Total Station Manual 5. Hidden Point The function of Hidden Point is using a specia hidden point measuring rod to measure the points which are not intervisible. The length of measuring rod is known, by measuring the position information of prism 1 and prism 2 in the measuring rod and using mathematical methods to calculate the coordinate of hidden point on the other side of the measuring rod.
  • Page 53 Total Station Manual Inputting the correct value of Rod length and [F4] pressing [F4] to back to measure the first prism point. 4 The instrument aims at [F1] the prism on the top and pressing [F1] finish [F2] measuring the first prism and enter the interface of [F3] measuring the second prism.

  • Page 54: Free Coding

    Total Station Manual Display the result of hidden point measurement. 6. Free Coding Please refer to 3. Q-Survey 3. Start Measurement 3.4 Code 7. Laser Pointer Open or close the laser fastly. 8. Light Turn on or off the light of instrument screen fastly. Open the second page of Function Menu and press [F4] to turn on or off the Light.

  • Page 55: Main Setting

    Total Station Manual Open the third page of Function Menu and press [F1] to enter the interface of unit setting. After finishing setting the units in the interface of Unit Setting, press [F4](OK) to save the settings,press [F1](Reset)to restore all units to factory default. 10.

  • Page 56: Edm Tracking

    Total Station Manual 11. EDM Tracking Open or close the mode of EDM Tracking fastly. Open the thied page of Function Menu, press [F3] to open or close the mode of EDM tracking.

  • Page 57: Applications

    Total Station Manual 5. Applications Prepare setting before measuring: Before startingthe application, there are some preparations needed to set up. The Pre-Settingsscreenwill beshown after the user selects an application. User can select and set the content of the Pre-Settings menu successively. [*]: Setting has been done.
  • Page 58 Total Station Manual 2 Press [F2](New) and then enter the Create a New Job screen. Press [F4](OK), the displayed [F1] job will be set as current job and then back to Pre-Settings screen. 3 If the instrument is fitted with SDCard, there willfirstly showthe diskselection screen.

  • Page 59: Select Anexisting Job From Memory

    Total Station Manual : The instrumentsystem will create and add date and time automatically. 1.2 Select anExisting Job from Memory If there is any job existing in the memory, user can select this job and set it as the current job. Steps Display Press...

  • Page 60: Setting The Station

    Total Station Manual job. Back Pre-Setting [F4] screen.The completed setting item is marked with *. Don’t pull out the SDCard when it is in operating state, otherwise it will cause the SDCard’sdata loss or damage. All measureddatas are stored in the current job. If start the application without setting the job, press ALL key or press REC key in the Q-Surveying screen, the instrument system will create a job which named DEFAULT automatically.

  • Page 61: Select The Coordinate From Memory [Find]

    Total Station Manual 2.1 Select the coordinate from memory [Find] Steps: Select the coordinate from memory. Input instrument height. [OK] Set station. Steps Display Press [F2] [F2] Pre-Settings screen. Then enter the Set STA function. Input 2 Input the name of the station point name point which exists in the job and...

  • Page 62: Select The Fix Point In The Memory [List]

    Total Station Manual the point is found, press [OK] in the [Find Pt.] list screen to set it as station. Program enter input instrument height screen. If the point doesn’t exist, press [F3](Coord.) input Back coordinates of N, E and Z. Set this point as station.
  • Page 63 Total Station Manual 2 Press [F2](List) in the [F2] [Set STA] screen. 3 Show the point list all the fix points and measured points of the current job. [View]: 4 Select the needed point through Up and Down key. [View]: Show informations of this point.

  • Page 64: Input The Coordinates Manually

    Total Station Manual [F4] 5 After selecting needed input point, press [F4](OK) and instrument enter input instrument height height screen. Complete all settings then back [ENT] Pre-Settings screen. [F4] 2.3 Input the coordinates manually. Steps: 1. Press [Coord.], enter input coordinate screen. 2.

  • Page 65: Setting The Orientation

    Total Station Manual 4 Press [F4](OK) to save [F4] the coordinates of this point. Program Input prompts"Saved!" Then enter instrument input instrument height height screen. Input the instrument height and press [ENT] to [ENT] confirm. Then press [F4] [F4](OK) finish setting.
  • Page 66 Total Station Manual Steps Display Press [F3] [F3] Pre-Settings screen. Then enter the Set STA function. 2 Press [F1] and select the [F1] [Angle Setting] input orientation manually. 3 Aim B.S. point and then Input horizontal input the azimuth, prism angle height and backsight point name.

  • Page 67: Set Orientation With Coordinates

    Total Station Manual Back to Pre-Settings screen. The setting items that have been made are marked with *. 3.2 Set orientation with coordinates The determination of the direction value can also be carried out using a point with a known coordinate. Steps: 1.

  • Page 68: Starting The Applications

    Total Station Manual 3 Aim backsight point and then press [ENT]. Press [F1](ALL) or press [F2](DIST) and [F3](REC) to start measuring and finish setting orientation. User can also press [F3](REC) to finish [ENT] setting orientation without measurement. [F1] [F2] [F3] Press the [PAGE] key to switch display...

  • Page 69: Surveying

    Total Station Manual Stakeout Free Station Tie Distance Area Remote Height COGO Road Steps: 1. Go to the MAIN MENU. 2. Move the focus to [Program] or press the Numeric key 2 to select and go to the PROGRAM MENU. 3.
  • Page 70 Total Station Manual 1 After finishing setting the job, setting the station and [F4] setting the orientation, press [F4] to start the application in the Pre-Setting menu. Input 2 Input the point name, and point then press [ENT] to move to name next input item to input prism height.
  • Page 71 Total Station Manual point. At this time, the screen remains the last measured data which can be looked over by pressing [PAGE].

  • Page 72: Individual Point

    Total Station Manual 5.1 Individual Point [IndivPt]: In the data acquisition, point can be recorded individually. Press this key to switch the screens of Individual Point Measurement and Consecutive Point Measurement. Steps Display 1 Press [F4]( ) twice to [F4] display the last page of soft keys.

  • Page 73: Data

    Total Station Manual [F1] 4 Press [F1](ALL) or press [F2](DIST) and [F3](REC) to [F2]+[F3 start measuring and record the measured data. Finish measuring, application turn function measuring individual point and then continue display consecutive point name. 5.2 Data [Data]: Look over the measured datas which are saved in current job. Steps Display 1 Press [F4](...
  • Page 74 Total Station Manual 3 After inputting the target Input point’s name or wildcard (*), point press [ENT] and then press name/ [F4](View) to look over the wildcard datas. If there is no match point, program [ENT] prompts“Pt. not found!” [Job]: Select the job where the [F4] measureddatais to be viewed.

  • Page 75: Stakeout

    Total Station Manual 6. Stakeout The Stakeout Application can calculate lofting elementsbase on lofting point’s coordinate or manually input angle or horizontal distance. The application can continuously display differences, between current position and desired stake out position. Steps of Stakeout : 1.
  • Page 76 Total Station Manual The program searchs the point name in the job and show the result dialog. The match points will be listed, press [F4](OK) to identify selected point and back to Stakeout screen. (If the input is wildcard "*", the program will show all the points of the current job.) If there is no match point...
  • Page 77 Total Station Manual Manual input stakeout point Press key [Coord.] or [SO-PT] to manual input stakeout point coordinates and then continue staking out. [Coord.]: Press [Coord.] and then input a target point’s coordinates. Saved this point into job and continue staking out. Steps Display 1 Press [F4] (...
  • Page 78 Total Station Manual [SO-PT]: Press [SO-PT] to input a stakeout point without point name and being saved into job. Steps Display 1 Press [F4] ( ) to view [F4] the third page of soft keys. [F2] 2 Press [F2](SO-PT) to go to SO-Input data screen.

  • Page 79: Polar Stakeout Mode

    Total Station Manual 6.2 Polar Stakeout Mode The meanings of the differencesin thePolar Stakeout mode: Difference in direction:If the measured point is located in the right side of stakeout point, the value is positive. Difference in horizontal distance: If the measured point is farther than stakeout point, the value is positive.
  • Page 80 Total Station Manual [PAGE] 2 Press [PAGE] to go to page 1/3(Default page). Press direction key and move the cursor to input prism height Input item. Input the prism height prism and then press [ENT] to height confirm. [ENT] 3 Aim at the prism. Press [F2](DIST) to start measuring [F2] and calculate the differences...
  • Page 81 Total Station Manual move. 6 Move the prism according to the direction of the arrow to make the value of equal 0m. Arrows Meaning: : Move the prism close to the station. : Move the prism far away the station. In the process of staking out, using Repeat...

  • Page 82: Orthogonal To Stationstakeout Mode

    Total Station Manual 8 Now itfinishes staking out a point.Repeat the previous steps to stake out next point. 6.3 Orthogonal to StationStakeout Mode Use longitudinal difference and perpendicular difference to indicatethe position differences of stakeout point and current prism position. The meanings of the differencesin theOrthogonal to StationStakeout Mode: Length Difference in longitudinal distance: If the measured point is farther...
  • Page 83 Total Station Manual 2 Press direction key and move the cursor to input prism Input height item. Input the prism prism height and then press [ENT] to height confirm. [ENT] 3 Aim at the prism. Press [F2](DIST) to start measuring and calculate the differences between measured point and [F2]...
  • Page 84 Total Station Manual Turn instrument telescope to find the direction where makes the Trav. equal 0m and command the staff to move the prism at the same time. Arrows Meaning: : Look forward from station and move the prism to the left. : Look forward from statio and move the prism to the right.

  • Page 85: Cartesian Stakeout Mode

    Total Station Manual 6.4 Cartesian Stakeout Mode Stake out point based on the Cartesian coordinate system. The deviation values are the coordinate differences. The meanings of the differencesin theCartesian Stakeout Mode: Y/E The difference in East coordinate between measured point and stakeout point.
  • Page 86 Total Station Manual 2 Press direction key and move the cursor to input prism Input height item. Input the prism prism height and then press [ENT] to height confirm. [ENT] 3 Aim at the prism. Press [F2](DIST) to start measuring [F2] and calculate the differences between measured point and...
  • Page 87 Total Station Manual In the process of staking out, using Repeat Measurement Tracking Measurement, the calculation of the differences between measured point and stakeout point can be displayedin real time and convenient. 6 It means the current prism position is effective stakeout point while both the Y/E and X/N are 0.

  • Page 88: Polar]

    Total Station Manual 6.5 [Polar] Press [Polar], then input the polar stakeout elements: Azimuth and Horizontal distance. Start to stake out after finishing inputs of Azimuth and Horizontal distance. Steps Display 1 Press [F4]( ) twice to [F4] view the second page soft keys.
  • Page 89 Total Station Manual 4 Aim at the prism. Press [F2](DIST) to start measuring [F2] and calculate the differences between measured point and stakeout point. Turn instrument telescope to make the equal 0°00’00” and command the staff to move the prism at the same time.
  • Page 90 Total Station Manual 7 Move the prism along the arrow direction to make the value of equal 0m. In the process of staking out, using Repeat Measurement Tracking Measurement, the calculation of the differences between measurement point stakeout point displayedin real time and convenient.

  • Page 91: Resection

    Total Station Manual 7. Resection Resection measurement is an application used to determine the coordinate of the instrument station by measuring multiple known points. A minimum of 2 and a maximum of 5 known points can be used to determine the station. It should be used at least 2 known points by distance measurement or at least 3 known points by angle measurement.
  • Page 92 Total Station Manual 4 The window back to the [F2] [Resection] window, press [F2] to set error limits. 5 Press [◄] \ [►] to turn on Input the error limits status and use error the key [▲] \ [▼] to move limits the focus down to input the every error limit.
  • Page 93 Total Station Manual angle. Distance measurement: [F1] (ALL) or [F1] + [F2] (DIST + REC). 9 When finish a known point measurement, press [F2] (NEXT PT) to start next [F2] known point measurement. Repeat steps 7 and 8 . 10 If the measured known points are enough, [Result] will display on the screen, then press [F3] (Result) to...
  • Page 94 Total Station Manual : The known points can be called from the memory through the [Find], [List] or manually entered used [Coord.].

  • Page 95: Tie Distance

    Total Station Manual 8. Tie Distance Tie Distance is an application used to compute slope distance, horizontal distance, height difference and azimuth of two target points which are either measured, selected from the memory, or input using the keypad. The user can choose between two different methods: Polygonal: P1-P2, P2-P3, P3-P4 Radial: P1-P2, P1-P3, P1-P4 Start Tie Distance application through “Main Menu”...
  • Page 96 Total Station Manual 2 After finishing setting job, station and orientation, [F4] press [F4] in the Pre-Setting menu to go to Select Tie Distance Mode screen. 3 Press [F1] to select the [F1] Polygonal tie distance. 4 Start to measure the first PAGE1 Press target point.
  • Page 97 Total Station Manual Start to measure the PAGE1 Press second target point. Aim at [F1] the second target point and press [F1](ALL) [F2] + [F2](DIST) + [F3](REC) to [F3] finishing measurement. Show the result of polygonal tie distance. [NewPt1]: Start polygonal tie distance.

  • Page 98: Radial

    Total Station Manual 8.2 Radial While Radial tie distance measuring continuous points, the new tie distance’s first point continues usingthethe previous tie distance’s first point(P1-P2 P1-P3 P1-P4 Steps Display 1 Press [F4] in the Program [F4] Menu to go to Tie Distance application.
  • Page 99 Total Station Manual 3 Press [F2] to select the [F2] Polygonal tie distance. 4 Start to measure the first PAGE1 Press target point. Aim at the first [F1] target point press [F1](ALL) or [F2](DIST) + [F2] + [F3](REC) finishing [F3] measurement.
  • Page 100 Total Station Manual 6 Show the result of Radial tie distance. [NewPt1]: Start a new Radial tie distance. [NewPt2]: This Radial tie distance’s first point continues to be the new polygonal tie distance’s first point and then go to 5 to measure the new second target point.

  • Page 101: Area

    Total Station Manual 9. Area Area is an application used to calculate the polygon areas to a maximum of 20 points which connected by straights. The target points coordinate can be measured, selected from memory or entered via keypad in same direction. And the following three methods can be alternately performed.
  • Page 102 Total Station Manual 2 After finishing the pre-settings (know [F4] more details at the beginning of chapter 5), press [F4] to start Area app. There are four ways to get target point Area A: Get the target point by measure. calculation.
  • Page 103 Total Station Manual is in memory, if exist, [F4](OK) then press [F4](OK) to be selected for calculating; exist, then need to input or measure the point. D: Input the point through keyboard. [F2](Coord. Press [F2] (Coord.) to input a Input point that not exist in Coord.

  • Page 104: Remote Height

    Total Station Manual 6 If the target points are set, then can press [F3](Result [F3] (Result) to show [Area Result] window to view the result. In [Area Result] window: Press [F1] (New Area) to restart a new Area application. Press [F2] (Graph) to show the area graph projected onto the horizontal plane. Press [F4] (Add PT) to return the current Area application and continue operation.
  • Page 105 Total Station Manual Steps Display Select “Program” from [PAGE] the [Main Menu] window, then press [PAGE] switch to [F2] second program list and press [F2] or number key [6] to enter the Area application. After finishing pre-settings (know more details at the beginning of [F4] chapter 5), press [F4] to enter the [Base Pt.] window...

  • Page 106: Prism High Unknown

    Total Station Manual 10.1 Prism High Unknown If the high of prism is unknown, the calculation formula of the remote height is: H = S * cosα * tanα – S * sinα * tanα Height difference between the base point and the remote point Prism High Slope distance between instrument and prism α...

  • Page 107: Cogo

    Total Station Manual 4 Move the prism just standing below the remote [F1] or point, then aim at the bottom [F2]+[F3 of prism rod and press [F1] (ALL) or [F2] + [F3] (DIST + REC) to finish the base point measuring. Turn the instrument telescope aimed at prism and...
  • Page 108 Total Station Manual Figure 11.1 Traverse Diagram Known known point Direction from P1 to P2 Distance between P1 and P2 Positive offset to the right Negative offset to the left Unknown COGO point without offset COGO point with negative offset COGO point with positive offset Steps Display...
  • Page 109 Total Station Manual 2 After finishing the pre-settings (know [F4] more details at the beginning of chapter 5), press [F4] to start COGO app. [F1] 3 In [COGO Menu] screen, press the [F1] or number key [1] enter the [Traverse & Inverse] screen, press [F2] or [2] enter the [F2]...
  • Page 110 Total Station Manual the “T.H.” field in COGO-Meas. [COGO-Meas], then aim the prism and press [F1] (ALL) or [F2] (DIST) + [F3] (REC) to measuring and saving the point traverse calculation. B: Press [F1](List) in B: Select the point by list in the memery. [Traverse] screen, use the key [▲]\[▼] to [F1](List)
