EEI -1321
DESK
HOW TO USE CAN AND CAM POST HARDWARE
1.
3.
5.
Note cam arrow
direction
STEP 1:
Place 1pc Side Drawer Front (N1),1pc Side Drawer Back,1pc Left Drawer Side (N3), 1pc Right Drawer Side (N4) and 1pc
Side Drawer Bottom (N5) together as shown.
Attach them by 2pcs Cam Post (a), 2pcs Cam (b), 4pcs Screw (c), tighten the Screws (c) and Cam (b)
Attach 1pc Pull (e) to the Side Drawer Front (N1) by using 2pcs Pull Screw (d).
Fully tighten Cams (b), Screws (c), Pull Screws (d) with Phillips Head Screw Driver (not included).
Repeat the same steps and hardware for the other Side Drawer and Centre Drawer as shown.
N4
c
N2
c
ax6 bx6 cx12
Customer Service 908-368-1025︱www.modwayfurniture.com
a
d
b
a
N5
N3
dx6 ex3
2.
4.
Turn cam clockwise
1/2 turn
e
N1
c
L2
c
Phillips Head Screwdriver
Hardware & Tools required
( not included)
Note cam arrow
direction
a
N4
d
b
b
L5
N3
c
e
L1
a
