CIO-DAC08 User's Guide

Environmental

Operating temperature range
Storage temperature range
Humidity

Main connector and pin out

Connector type
Compatible cables
Compatible accessory products
with the C37FF-x cable or
C37FFS-x cable
Pin Signal Name
1 D/A OUT 0
2 D/A OUT 1
3 D/A OUT 2
4 D/A OUT 3
5 D/A OUT 4
6 D/A OUT 5
7 D/A OUT 6
8 D/A OUT 7
9 NC
10 NC
11 NC
12 NC
13 NC
14 NC
15 NC
16 NC
17 +12V
18 GND
19 +12V
Table 3. Environmental specifications
0 to 70 °C
-40 to 100 °C
0 to 90% non-condensing
Table 4. Connector specifications
37-pin male "D" connector
C37FF-x
C37FFS-x
DFCON-37 (D-connector, D-shell, and termination pins to construct your own cable)
CIO-MINI37
CIO-TERMINAL
Table 5. Connector pin out
18
Pin Signal Name
20 LLGND
21 LLGND
22 LLGND
23 LLGND
24 LLGND
25 LLGND
26 LLGND
27 LLGND
28 LLGND
29 LLGND
30 LLGND
31 LLGND
32 LLGND
33 LLGND
34 LLGND
35 LLGND
36 +5V
37 GND
Specifications
