NOTICE This guide provides basic guidelines for the Rosemount 3095FC with Modbus Protocol. It does not provide instructions for configuration, diagnostics, maintenance, service, or troubleshooting. Refer to the Rosemount 3095FC MultiVariable Mass Flow Transmitter Reference Manual for more instruction. The manuals are also available electronically on EmersonProcess.com/Rosemount.
Quick Start Guide June 2016 1.0 Mount the transmitter 1.1 Installing the Rosemount 3095FC on a pipestand The following steps must be taken to install the Rosemount 3095FC on a 2-in. pipestand: 1. Install the pipestand using the pipestand documentation. 2.
Page 4
If the transmitter installation requires assembly of the process flanges, manifolds, or flange adapters, follow these assembly guidelines to ensure a tight seal for optimal performance characteristics of the transmitters. Use only bolts supplied with the transmitter or sold by Emerson as spare parts. Figure 2 illustrates common transmitter assemblies with the bolt length required for proper transmitter assembly.
Page 5
Quick Start Guide June 2016 Table 1. Torque Values for the Flange and Flange Adapter Bolts Initial Bolt material Head Markings Final Torque Torque 300 in-lb 650 in-lb Carbon Steel (CS) Stainless Steel (SST) 150 in-lb 300 in-lb 1.4 O-rings with flange adapters WARNING Failure to install proper flange adapter O-rings may cause process leaks, which can result in death or serious injury.
June 2016 Quick Start Guide 2.0 Connect wiring Use the following steps to wire the transmitter: 1. Remove the electronics housing cover on the side marked FIELD TERMINALS. 2. Wire the RTD. Temperature is input through the Resistance Temperature Detector (RTD) probe and circuitry.
Page 7
Quick Start Guide June 2016 Using the prefabricated operator interface cable, physically connect the Rosemount 3095FC to the PC running the Rosemount User Interface Software. One end of the cable (a 9-pin, D-shell, female connector) plugs into a serial communications port on the PC. The other end of the cable plugs into the Rosemount 3095FC.
June 2016 Quick Start Guide Figure 4. Rosemount 3095FC Terminal Block and Wiring Diagram 2 OR 3 WIRE RTD POWER SUPPLY OPERATOR INTERFACE CABLE A. LOI E. 2 or 3 wire RTD B. RET F. Power supply C. RTD G. PC D.
6.0 Trim the transmitter Note ™ Transmitters are shipped from Emerson Process Management, Emerson fully calibrated per request or by the factory default of full scale. 6.1 Zero trim A zero trim is a single-point adjustment used for compensating mounting position effects.
Page 10
June 2016 Quick Start Guide Perform the following steps: 1. Connect the Rosemount User Interface Software to the Rosemount 3095FC and run the calibration procedure. 2. Select Meter>Calibration >Freeze. 3. Under the Diff Press input, click Zero Shift to open the Set Zero Shift window. 4.
Rosemount website at EmersonProcess.com/Rosemount. A hard copy may be obtained by contacting our local sales office. ATEX Directive (94/9/EC) Emerson Process Management complies with the ATEX Directive. European Pressure Equipment Directive (PED) (97/23/EC) Rosemount 3095F_2/3,4/D Flow Transmitters —...
Page 12
June 2016 Quick Start Guide Figure 5. Rosemount 3095FC Declaration of Conformity...
Page 16
June 2016 Quick Start Guide Rosemount 3095FC China RoHS List of Rosemount 3095FC Parts with China RoHS Concentration above MCVs / Hazardous Substances Hexavalent Polybrominated Polybrominated Part Name Lead Mercury Cadmium Chromium biphenyls diphenyl ethers (Pb) (Hg) (Cd) (Cr +6) (PBB) (PBDE) Electronics...
Page 18
