IP 2.1MP Snapit Vandal Dome Camera
MV421D/B
MV421TIR/B
Quick Setup Guide

Additional Cabling Connections

SENSOR+ (Green)
Power
SENSOR- (Yellow)
RELAY- (Orange)
RELAY+ (Red)
UART+ (Brown)
UART- (Black)
Audio In/ Out
RJ45 Connector

Resetting the Camera

Pressing the reset button on the camera's control board for five (5) seconds will initialize all environmental
variables to factory default. Previous setup for IP default, time, etcetera will be deleted. If a system IP address is
lost, reset the camera back to factory default.The following are the default network settings:
IP Mode
DHCP
IP Address
192.168.1.123
Subnet Mask
255.255.255.0
Gateway
192.168.1.123
Command Port
7000
HTTP Port
80
Live Port
7001
Frequent use may cause a System Error
TEL: (866) 446-4359
www.Digital-Watchdog.com / technicalsupport@dwcc.tv
Technical Support Hours: Monday-Friday 8:30AM to 8:00PM EST

PREPARATION

The following items are included with the MV421D/TIR camera
CD
(Manual &
Quick Start
IP 2.1MP Snapit Vandal Dome Camera
Software)
MV421D/B
MV421TIR/B
Guide
Quick Setup Guide
Mounting
Template
4 Screws
4 Dry Wall
Anchors
Second Video
TROX-T20
Jack
L-Wrench
1
3
2
Thank you for purchasing Digital Watchdog's Snapit MEAPIX lndoor Dome Camera.
Before installing the camera, please verify your model and read this guide carefully.
Network Connection
There are two options.*
Using a PoE-Enabled Switch
1
The MEGAPIX Camera is PoE-compliant, allowing transmission of power and data via a single
ethernet cable. Follow the illustrations below to connect the camera to a PoE-enabled switch using
an ethernet cable.
Using a Non-PoE Switch
2
If a PoE-enabled switch is not used, use a power adaptor to connect the MEGAPIX Camera to a
Non-PoE switch.
2
12 1 3 2 0 1 2

INSTALLATION

Prepare the Camera and Mounting Surface
Use the camera's mounting template or
1
your camera to make holes as required.
Camea Module
Pull wires through and make connections.
3
1
Use the Cable Base to easily place all UNUSED
cables.
Audio In/ Out
2
Alarm In/Out
3
Sensor+ (Green)
Sensor - (Yellow)
Relay - (Orange)
Relay + (Red)
UART + (Brown)
UART - (Black)
Mount the Camera Surface Base to the wall.
5
3
Mount the Camera
The MEGAPIX Camera is designed to be surface mounted on a wall
or ceiling.
Snap the camera module into the base by
6
aligning the red and black markings on the base
and the camer module.
Adjust the camera's position by using
8
the 3-Axis Gimbal.
Tighten the four locking screws in
10
with the L-wrench to secure the cover
dome over the camera.
4

SPECIFICATIONS

Lens Specifications
Lenses are pre-focused at the factory. In the unlikely event that
the optical effect of the dome cover cause a slight defoucsing
of the lens, hold the dome cover over the lens to make a final
adjustment.
o
Y-Axis: 90
Tilt for MV421D
1
o
82
Tilt for MV421TIR
X-Axis: 360
o
Pan
2
Drill holes into the drywall and insert the
2
drywall mounts.
NO IR
Rotation 360
Connect the RJ45 to a CAT5 cable or a
4
power adaptero.
NO IR
Tilting 90
Over-rotating the lens will damage the camera lens module
5
Camera Specifications
Image Sensor
Total Pixels
Minimum Scene Illumination
LENS
Focal Length
Lens Type
IR Distance
Digital Zoom / Optical Zoom
OPERATIONAL
Mirror & Flip
3D-Digital Noise Reduction
Privacy Zone
Motion Detection: Sensitivity
Secure the three (3) Assembly Screws.
7
Alarm Notifications
NETWORK
LAN
Video Compression Type
Resolution
Frame Rate
Streaming Capability
IP
Protocol
Maximum User Access
ONVIF Conformance
Web Viewer
SCheck the LED light. Green light flickers
9
for booting. Red light turns on when booting
Video Management Software
is complete.
Memory Slot
ENVIRONMENTAL
Operating Temperature/ Humidity
Operating Humidity
Storage Temperature
Other Certifications
ELECTRICAL
Power Requirement
Power Consumption
MECHANICAL
Material
Dimensions
Weight
6
IR
NO IR
IR
o
Panning 360
o
IR
o
Tilting 75
o
7
1/2.8" CMOS Sensor (7% Larger Than 1/3" CMOS Sensor)
2016 (H) X 1108 (V)
F1.6 (30IRE): 0.5 Lux [Color]
F1.6 (30IRE): 0.0 Lux [B&W]
3.5-16mm
Auto Focus
70ft Range
8X / 4.5X
Off, On
Off, Low, Middle, High
Off, On (30 Programmable Zones)
Low, Middle, High
Notifications Via E-mail
802.3 Compliance 10/100 LAN
H.264, MPEG4, MJPEG (Super Fine~Low)
1920X1080 (16:9) ~ 320X240 (4:3)
Up to 30fps at All Resolutions
Dual-Stream at Different Rates and Resolutions
IPv4, IPv6
TCP/IP, HTTP, DHCP, PPPoE, ICMP, ARP, RARP,
RTSP, NTP, UDP, Multicast
20 Users
Yes
OS: Windows XP / Vista / 7, MAC OS
Browser: Internet Explorer, Chrome, Firefox, Safari
NxMS, Pivot
Up to 24 Hour to Micro SDHC Card (4GB-32GB)
Card Not Included*
-10
o
C ~ 55
o
C (14
o
F ~ 131
o
F)
Less than 90% (Non-Condensing)
-20
o
C ~ 70
o
C (-4
o
F ~ 158
o
F)
CE, FCC, RoHS
DC 12V, PoE (IEEE802.3af Class 3)
7.2W, 600mA / LED ON 8.64W, 720mA
Plastic
108 X 96.8 mm (4.25 X 3.8 in)
0.529 lbs
8
