Digital Watchdog MC421D Quick Start Manual

MC421D
IP 2.1MP Color Box Camera
Quick Setup Guide
Additional Cabling Connections
+
RELAY OUT
-
+
SENSOR IN
-
VIDEO OUT
MICRO SD
PWR
RESET
DC12V
RS485
/AC24V
+ - ETHERNET / PoE
AUDIO
IN/OUT
Audio In/ Out
RJ45 Connector
Resetting the Camera
Pressing the reset button on the camera's control board for five (5) seconds will initialize all environmental
variables to factory default. Previous setup for IP default, time, etcetera will be deleted. If a system IP address is
lost, reset the camera back to factory default.The following are the default network settings:
IP Mode DHCP
IP Address 192.168.1.123
Subnet Mask 255.255.255.0
MICRO SD
Gateway 192.168.1.123
PWR
Command Port 7000 RESET
RS485
ETHERNET / PoE
HTTP Port 80 + -
Live Port 7001
Frequent use may cause a System Error
TEL: (866) 446-4359
www.Digital-Watchdog.com / technicalsupport@dwcc.tv
Technical Support Hours: Monday-Friday 8:30AM to 8:00PM EST
PREPARATION
The following items are included with the MV421D/TIR camera
Quick Start
Guide
TROX-T20
L-Wrench
Mount Adapter
Second Video
Terminal Block
Jack
Thank you for purchasing Digital Watchdog's Snapit MEAPIX lndoor Dome Camera.
Before installing the camera, please verify your model and read this guide carefully.
Network Connection
There are two options.*
Using a PoE-Enabled Switch
1
The MEGAPIX Camera is PoE-compliant, allowing transmission of power and data via a single
ethernet cable. Follow the illustrations below to connect the camera to a PoE-enabled switch using
an ethernet cable.
Power
Using a Non-PoE Switch
2
If a PoE-enabled switch is not used, use a power adaptor to connect the MEGAPIX Camera to a
Non-PoE switch.
+
RALAY OUT
-
+
SENSOR IN
-
VIDEO OUT
DC12V
/AC24V
AUDIO
IN/OUT
2
02 2 2 2 0 1 3
INSTALLATION
Prepare the Camera and Mounting Surface
CD
(Manual &
Software)
CS Lens
Use the camera's Mounting accessory
1
2 Port to mark drilling holes on the mounting
surface.
Color Box IP
Camera
Attach the box camera to the mounting
3
bracket & adjust the camera's position.
Consult the mounting bracket's manual for
additional information.
3
Mount the Camera
The MEGAPIX Camera is designed to be surface mounted on a wall
or ceiling.
Locate the SD card slot in the back of the camera
6
module. Insert the SD card in the slot and push it
down, until you hear a 'click' sound. See page 16
in this QSG for more information on setting up an
emergency recording schedule.
Connect the RJ45 to a CAT5 cable or a
7
power adaptor. If necessary, connect the
Audio In and Out, and Relay Control cables.
Check the LED light. Green light flickers for
booting. Red light turns on when booting is
complete.
4

SPECIFICATIONS

Lens Specifications
If you are using an automatic iris lens with the camera, the lens has
to be connected to the A-Iris socket of the camera. If you are using
a lens with manual or fixed iris, this socket is not used.
Operation of the camera will be confirmed by the power LED at the
rear side of the camera.
CS-Mount lens
After removing the protecting cap,
attach the lens into the camera by
turning clockwise.
Drill holes into the drywall and mount the
2
camera's mount.
Attach an appropriate Lens to the camera.
4
See page 7 in this QSG for more information.
5
Camera Specifications
Image Sensor
Total Pixels
Minimum Scene Illumination
AUDIO
Compression and Sampling Rate
Input / Output
OPERATIONAL
Brightness
Shutter Mode
Digital Slow Shutter
DNR (Digital Noise Reduction)
Auto Gain Control
BLC (Backlight Compensation)
WDR (Wide Dynamic Range)
Day and Night
Lens Mode
Chroma (Hue & Saturation Settings)
Sharpness
Mirror & Flip
Sensor In/ Out
Alarm Notifications
NETWORK
LAN
Video Compression Type
Resolution
Frame Rate
Streaming Capability
IP
Protocol
Maximum User Access
ONVIF Conformance
Web Viewer
Video Management Software
Memory Slot
ENVIRONMENTAL
Operating Temperature/ Humidity
Operating Humidity
Adjust the lens' zoom and focus accordingly.
Storage Temperature
8
Consult the manual for the lens for more Other Certifications
ELECTRICAL
information.
Power Requirement
Power Consumption
MECHANICAL
Material
Dimensions
Weight
6
C-Mount lens
1. Attach the C-Mount lens adapter by turning clockwise.
2. Attach the lens to the camera by turning clockwise.
Adapter Ring
A-IRIS 4
2
DC Driven (DC)
1.control -
2.control +
3.drive +
4.GND
3 1
NOTE
C-Mount Lens : 10mm or less
CS-Mount Lens : 5mm or less
7
1/2.8" Sony CMOS Sensor
2016 (H) X 1108 (V)
F1.6 (30IRE): 0.5 Lux [Color]
F1.6 (30IRE): 0.01 Lux [B&W]
G.711 (8KHz)
1 Line In and 1 Line Out Mono
0~20
Auto, Manual
Off, 2X, 3X, 4X
Off/ Low/ Middle/ High
0~20
Off, On
Off, On, Level 0~9
Auto, Day (Color), Night (B/W)
Manual, DC
0~20
0~10
Off, On
1 Input/ 1 Output Built-In
Notifications Via E-mail
802.3 Compliance 10/100 LAN
H.264, MPEG4, MJPEG (Super Fine~Low)
1920X1080 (16:9) ~ 320X240 (4:3)
Up to 30fps at All Resolutions
Dual-Stream at Different Rates and Resolutions
IPv4, IPv6
TCP/IP, HTTP, DHCP, PPPoE, ICMP, ARP, RARP,
RTSP, NTP, UDP, Multicast
5 Users
Yes
OS: Windows XP / Vista / 7, MAC OS
Browser: Internet Explorer, Chrome, Firefox, Safari
DW Spectrum/ NxMS/ Pivot
24 hours recording to Micro SDHC Card (4GB-32GB)
Card Not Included*
o o o o
-10 C ~ 50 C (14 F ~ 122 F)
Less than 90% (Non-Condensing)
o o o o
-20 C ~ 70 C (-4 F ~ 158 F)
CE, FCC, RoHS
DC 12V, PoE (IEEE802.3af Class 2)
6.5W, 550mA
Aluminum Housing
131.3 X 55 mm (5.2 X 2.17 in)
0.55 lbs
8
