GE AT600 User Manual page 91

Register Register (in
(in Hex) Decimal)
706
708
70A
740 740
900 900
902
904
906
908
90A
90C
90E
910
940 940
942
944
946
948
A00 A00
A02
A04
A06
C00 C00
C02
C04
C06
C08
C0A
C40 C40
C42
C44
AT600 User's Manual
Table 5: MODBUS Map (cont.)
Access Level
1798 RO
1800 RO
1802 RO
1856 RO
2304 Viewer
2306 User
2308 User
2310 Viewer
2312 Viewer
2314 Viewer
2316 Viewer
2318 Viewer
2320 Viewer
2368 User
2370 User
2372 User
2374 User
2376 User
2560 RO
2562 RO
2564 RO
2566 RO
3072 User
3074 User
3076 User
3078 User
3080 User
3082 User
3136 User
3138 User
3140 User
Description
System Flow error Bitmap
System Device error Bitmap
System Warning Bitmap
System Protocol type
Display Language
Display Backlight Enable
Display Timeout
Display Type
Display Variable1 Type
Display Variable2 Type
Display Totalizer1 Type
Display Totalizer2 Type
Display Decimal selection
select the velocity
select the Actual Volumetric
select the Standardized
Volumetric
select Mass
select Totalizer
Display Variable1 Value
Display Variable2 Value
Display Totalizer1 Value
Display Totalizer2 Value
Analog Out Error Handling
Value
Analog Out Test Value
(Percent of Span)
Analog Out Zero Value
Analog Out Span Value
Analog Out Base Value
Analog Out Full Value
Digital Out 1 Pulse Value
Digital Out 1 Frequency Base
Value
Digital Out 1 Frequency Full
Value
Chapter 5. Communication
RO/RW Format
RO INT32
RO INT32
RO INT32
RO INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
79
