Outboard pilot,
Hydraulic pack
Installation Guide
ENGLISH
*988-10717-002*
www.simrad-yachting.com | www.lowrance.com
PLANNING: GS25/Point-1, Mounting location
Magnetic Field
RADAR
2 m (6 ft) Min
1 m (3.3 ft) Min
0.5 m (20") Min
0.5 m (20") Min
Radio Transmitter
RC42N
Electromagnetic Interference
GS25/Point-1
The antenna contains a magnetic heading sensor and should not be
mounted within 1 meter (3.3 ft) of any potential magnetic source.
RC42N
Select a location that provides a solid mounting place free from
vibration, min. 1 meter (3.3 ft) away from any potential magnetic
source, and as close to the vessel's centre of roll and pitch as
possible, i.e. close to the water line.
Potential sources for magnetic/electromagnetic interference include:
Electrical Motors/Magnets/Moving Metal items
•
Outboard Engines
•
High current electrical sources such as main power cables,
•
batteries, distribution panels etc.
Technical specifications
NAC-1
Operating temperature
-25°C to +55°C (13°F to 131°F)
Protection
Splashproof, IPx5
Weight
0.6 kg (1.3 lbs)
Power supply
9-16 V DC
140 mA + drive unit load
Load
Performance
Drive: 8 A cont., 16 A for 1 s
Pump-1
Operating temperature
-15°C to +75°C (5°F to 167°F)
Splashproof, IPx5
Protection
Weight
2.2 kg (4.9 lbs)
Load
5 A at 8 bar (116 psi), 7 A at 24 bar (350 psi)
Performance
0.8 l/min at 24 bar (350 psi)
GS25/Point-1
Operating temperature
-25°C to +60°C (13°F to 140°F)
Protection
Watertight, IPx7
Weight
0.14 kg (0.31 lbs)
9-16 V DC
Power supply
Load
<100 mA @ 12 V DC
Performance
Heading: +/- 3°, Horiz. accuracy: 3 m (9.8 ft)
Standby/Auto button
Operating temperature
-25°C to +55°C (13°F to 131°F)
Splashproof, IPx5
Protection
0.04 kg (0.09 lbs) (including cable)
Weight
RC42N
Operating temperature
0°C to +55°C (32°F to 131°F)
IP56
Protection
Weight
0.4 kg (0.9 lbs)
Power supply and interface
8-16 V via NMEA 2000
1.4 W
Power consumption
± 3 degrees after calibration
Accuracy
Compass safe distance
0.5 m (1.7')
PLANNING: Pump-1, Mounting location
5
Compatibility information
The hydraulic kit comes with 1/4 NPT 9/16 UNF fittings for nylon
tube or flexible hoses which make them ideally suited for the
following steering systems:
•
Teleflex SeaStar HC5345, HC5347, HC5348, HC5358.
•
Teleflex BayStar HC4600, HC4645, HC4647, HC4648, HC4658.
•
Hynautic K6 Steering Rams.
•
Also rams from Vetus, Uflex, Lecomble and Schmitt can be used.
PLANNING: Tools needed
1
Use to mount Pump-1, NAC-1 and heading sensor.
Drill holes for screws, larger dimensions for hoses.
Wrenches that fit the hoses.
Cup or can for oil spill.
Tape.
1
Tools to connect power cables at battery.
1 * Ø 16 mm (0.62")
Gloves (disposable type).
2
NOTE:
THE CONNECTION ARE
PLANNING: Cable lengths
COLOR INDEPENDENT
Refer to Wiring diagram (point 15) to find the various
cable lengths.
Installing with optional 000-11772-001 Verado
6
fitting kit for Pump-1
HIGH PRESSURE
STEERING LINES
VERADO HELM
CORRECT
FLUID LEVEL
HIGH PRESSURE
STEERING LINES
HIGH PRESSURE
SUPPLY LINE
LOW PRESSURE
RETURN LINE
STEERING LINES
www.busse-yachtshop.de | info@busse-yachtshop.de
PLANNING: Dimensions
2
128.0 (5.0")
204 mm (8.1")
183 mm (7.2")
169 mm (6.63")
3
155 mm (6.1")
76 mm (3")
MOUNTING: Disconnecting the hoses from helm
7
pump
VERADO STEERING
CYLINDER VOLUME
APPROX. 9ci - 150 cc
LOW PRESSURE
RETURN LINE
VERADO ELECTRO
HYDRAULIC POWER PACK
HIGH PRESSURE
SUPPLY LINE
RETURN LINE
EXTENSION
310 mm
STEERING LINE
EXTENSION
RETURN LINE
930 mm
4
34.0 (1.3")
90.0 (3.5")
106.4 (4.2")
ø 90 mm (3.5")
38 mm
(1.5")
57 mm
(2.2")
91 mm
(3.6")
190 mm
180 mm
(7.5")
(7.1")
100 mm (4")
85 mm
(3.4")
85 mm (3.4")
8
1
2
3
1
2
1
1
