DIAGRAM OF COMPONENTS

Pads Connector Socket –
Socket for pads connector
ON/OFF Button –
Turns AED on and off
Display Screen –
Displays video,
text prompts
and information
SHOCK Button –
Flashes when a
shock is advised.
Pressing this button
will deliver a shock
when the button is
fl ashing.
Speaker
FRONT OF AED
Defi btech Automated
External Defi brillator
OPERATING GUIDE
(For more detailed information,
refer to the User Manual
at www.defi btech.com)
6
DAC-A2530EN-BK
Active Status Indicator (ASI) –
Indicates the current status of the AED
Softkey Buttons
(Top, Center, Bottom) –
Buttons used to navigate
menus or select options
USB Port
Defi btech
Data Card
(DDC Card)
(Optional)
USB and Defi btech
Data Card (DDC Card)
Access Door – Access to the
USB connector port and
Defi btech Data Card slot
Operating Guide
Battery Pack Opening
Pad Storage Area
Pads
Connector
BACK OF AED
Defi brillation Pads
Expiration Date
(on back of package)
Defi brillation Pads
(inside of package)
DEFIBRILLATION
PADS PACKAGE
For more detailed information, refer to the User Manual (at www.defi btech.com).
Battery Pack
Eject Release
Latch
BATTERY PACK
7 7
DAC-A2530EN-BK
