Table Of Contents - Defibtech DDU-2300 Operating Manual

This manual applies to the following models and trade names
Trade Names
Lifeline/ReviveR VIEW
Lifeline/ReviveR ECG
The Lifeline/ReviveR VIEW is referred to as the DDU-2300 from this point forward in this manual.
The Lifeline/ReviveR ECG is referred to as the DDU-2450 from this point forward in this manual.
Statements that apply to all trade names/model numbers listed above are referred to in this manual
as "DDU-2000 Series. "
Notices
Defibtech, L.L.C. shall not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this material. Information in
this document is subject to change without notice. Names and data used in any examples are
fictitious unless otherwise noted.
For more detailed information regarding the Defibtech DDU-2000 Series AED, please refer to the
User Manual at www.defibtech.com.
Limited Warranty
The "Limited Warranty" shipped with Defibtech AED products serves as the sole and exclusive
warranty provided by Defibtech, L.L.C., with respect to the products contained herein.
Copyright
Copyright © 2018 Defibtech, L.L.C.
All rights reserved. Copyright questions should be directed to Defibtech. For contact information,
refer to the "Contacts" section of this guide.
Tracking
U.S.A. federal regulations require Defibtech to maintain records for each AED it distributes
(reference 21 CFR 821, Medical Device Tracking). These requirements also apply anytime there is
a change in the AED's location, including if you move, sell, donate, give away, export or even throw
it away. We depend on AED owners/users to contact us when these things happen to ensure the
tracking information remains accurate in the event we need to share important product notices.
If your location is outside the U.S.A., we ask you share your information for exactly the same
reasons. To keep your information up to date, please visit www.defibtech.com/register.
Federal Law (USA) restricts this
!
device to sale by or on the order
of a physician.
CAUTION
DAC-A2530EN-BK (Issued: 2018-06-08)
Model Number
DDU-2300
DDU-2450
Contents
Quick Use Instructions ...................................................................... 4
When to Use (Indications, Contraindications, Summary of Primary
Clinical Studies, Potential Adverse Effects of the Device on Health,
Operator Training Requirements) .......................................................... 5
Diagram of Components ................................................................... 6
Setting Up the AED ........................................................................... 8
Using the AED ...................................................................................10
Using the AED - ECG Display
The Defibrillation Pads .....................................................................15
The Battery Pack ...............................................................................16
The Defibtech Data Card
(optional)
Checking AED Status .......................................................................18
Maintenance ......................................................................................19
Troubleshooting............................................................................... 22
Warnings and Cautions ....................................................................24
Technical Specifications ................................................................. 26
Glossary of Symbols ....................................................................... 28
Warranty Information .......................................................................31
Contacts ............................................................................................ 32
This Operating Guide is to be used for concise guidance on set-up, use,
maintenance and technical specifications on DDU-2000 Series AEDs.
For comprehensive training on set-up, use and maintenance as well as complete
technical specifications, refer to the User Manual at www.defibtech.com
(DDU-2450 only) ............................................
....................................................17
DAC-A2530EN-BK
14
3
