4.

"WIZARD MODE"

In Wizard mode, Action Module records and repeats your slides. It will record the start and end positions and
average speed of your slide instantly. Also learns your avarege speed instantly. After selecting the mode,
follow these steps to record and playback your slides.
HOLD OK TO START RECORDING
1. Manually slide to your start position. Then press
OK and hold for 3 sec till see the "REC. " on the screen.
ACCEL.
3. Press OK to switch between acceleration & speed. Push
UP/DOWN to adjust your acceleraiton.
STATIONARY
RIGHT
Go to right point
LEFT Go to left point
HOLD RIGHT
Go to right point
HOLD LEFT
Go to left point
UP
DOWN
PRESS OK
Changes to the selection between "acceleration-speed"
DOUBLE RIGHT
Loop between right & left point
DOUBLE LEFT
Loop between right & left point
In this mode use hand control to move the camera
REC.
2. While "REC" is blinking move the camera
LEFT/RIGHT until you reach your end
point then stop and wait till "REC" goes away.
SPEED
4. Press OK to switch between acceleration &
speed. Push UP/DOWN to decide your speed.
IN MOTION
Stop
Stop
Stop
Stop
Increase speed
Decrease speed
Stop
Stop
5.

"MACRO MODE"

Macro Mode designed to perform extreme slow
slides.
You don't need trigger cable for this mode. Select the
mode and follow these steps. If action module is not
on macro mode, turn o the device and turn it on
again to be able to choose macro mode.
STATIONARY
RIGHT Starts moving to the right
LEFT Starts moving to the left
press and hold to LEFT/RIGHT to move faster and once the button
HOLD RIGHT/LEFT
is released, Action Module will revert to the orginal speed.
UPWARDS
DOWNWARDS
In macro mode system works in higher torques which may help you to operate in
inclined operations.
In these modes use left/right control buttons to move the camera. Do not operate the
slider by hand.
Before operating your product, please watch the users manual videos from the link: *Before operating your product, please watch the users manual videos from the link:
manual.edelkrone.com manual.edelkrone.com
Notice
MACRO MODE
050/100
IN MOTION
Stop
Stop
increase speed
decrease speed
