Single wire line interface: FREESCALE MCZ33897

Baud rate up to 33 Kbit/sec
-
Connection up to 32 stations on the bus
-
Transmission over 1 wire
-

2.4. Main characteristics of the KWP2000 connection

- ISO 9141 or ISO 14230 standard
- Baud rate 9600, 10400, 62500 and 125000 Bauds
- Tester (500 Ω) or simulator (30 kΩ) configuration set up by software

Line interface: tester mode

16/05/2012
Document confidentiel appartenant à Annecy Electronique S.A.S.
Ne peut être diffusé, copié intégralement ou en partie sans autorisation expresse préalable
+VBAT
R1 = 500 Ohm
00282805-v2
USB-MUX-6C6L – User guide
8
