4.1.
DB15 « I / O » connector
Analog/Digital inputs/outputs
Pin
Name
1
E_ANA/TOR_1
2
E_ANA/TOR_2
3
E_ANA/TOR_3
4
E_ANA/TOR_4
5
E_ANA/TOR_5
6
E_ANA/TOR_6
7
E_ANA/TOR_7
8
E_ANA/TOR_8
9
GND
10
S_TOR/PWM_1
11
S_TOR/PWM_2
12
S_TOR/PWM_3
13
S_TOR/PWM_4
14
S_TOR/PWM_5
15
S_TOR/PWM_6
4.2.
« DE9 CAN 1 / K-LIN 1 » to « CAN6 / K-LIN6 » DE9 connectors
CAN high speed, low speed, single wire, inputs/outputs channels
« CAN n / K-LIN n », n corresponding to the DE9 connector's number
Pin
Name
1
E_ANA/TOR_n
2
CAN_L_n
3
GND
4
LIN_n / ISO_K_n
5
E_WK
6
(GND)
7
CAN_H_n
8
S_TOR_1 / ISO_L_ 1
9
Vbat
16/05/2012
Document confidentiel appartenant à Annecy Electronique S.A.S.
Ne peut être diffusé, copié intégralement ou en partie sans autorisation expresse préalable
Denomination
0-32V analog or digital input n°1
0-32V analog or digital input n°2
0-32V analog or digital input n°3
0-32V analog or digital input n°4
0-32V analog or digital input n°5
0-32V analog or digital input n°6
0-32V analog or digital input n°7
0-32V analog or digital input n°8
Masse
0-32V digital or PWM output n°1
0-32V digital or PWM output n°2
0-32V digital or PWM output n°3
0-32V digital or PWM output n°4
0-32V digital or PWM output n°5
0-32V digital or PWM output n°6
Denomination
0-32V analog or digital input n°n
CAN Low of CAN bus n°n
Ground
LIN n°n or ISO K n°n
Wake tranceiver active input
Optional ground
CAN High / CAN Single Wire of CAN bus n°n
Digital 0-24V output n°n or ISO_L n°n
+CAN or +LIN
00282805-v2
