3.1.

Technical characteristics

Presentation
Controller
Line interface
Inputs / Outputs
Connectors
PC Interface
Dimensions
Time base
Power supply
Consumption
Storage temperature
Operating temperature
Isolation
16/05/2012
Document confidentiel appartenant à Annecy Electronique S.A.S.
Ne peut être diffusé, copié intégralement ou en partie sans autorisation expresse préalable

3. Technical specifications

PC interface box USB bus or Ethernet including:
- 6 x CAN high speed or CAN low speed / fault tolerant
or single wire channels
- 6 x LIN or ISO9141 channels
. CAN: 1 MULTICAN
. LIN / ISO9141: 3 USIC
. CAN high speed: TJA1040
. CAN low speed: TJA1055
. CAN single wire: MCZ33897
. LIN: MC33661 (Master or Slave)
14 x 0-32V analog or digital inputs (includes 1 timer in.)
6 x ISO9141 L or digital 0-24V output
6 x Digital / PWM outputs
1 x RS232 link
6 + 1 DE9 connectors
1 DA15 connector
1 external CF card slot + 1 internal CF card slot
USB 2.0 Hi-Speed bus (12 ou 480 Mbit/sec)
Ethernet 10/100 Mbit/sec Auto-MDIX bus
200 x 170 x 50 mm
500ns RTC clock
External 7-36V through specific connector or through
USB. Dedicated power supply for each line interface on
the front panel.
USB: 300 mA
External: 110 mA (USB)
External: 200 mA (Ethernet)
-40 à +85°C
-40 à +85°C (except DLC mode -25 à +85°C)
Optional
00282805-v2
USB-MUX-6C6L – User guide
11
