4.3. « DE9 IOIOI » DE9 connector
RS232 link (and optionally RS485)
Pin Name
1 SYNC_IN
2 RxD
3 TxD
4 SYNC_OUT
5 GND
6 RS485_Z
7 RS485_Y
8 RS485_A
9 RS485_B
4.4.

USB connector

USB standard B type connector
Pin Name
1 VBUS
2 D-
2 D+
4 GND
4.5.

Ethernet connector

Ethernet 10/100 connector
Pin Name
1 TX+
2 TX-
2 RX+
4 TXCT
5 TXCT
6 RX-
7 RXCT
8 RXCT
4.6.

External power supply connector

[7 – 36] volts – 1 A max
JACK 2,5mm connector (lockable)
