Owner's Manual & Installation Instructions
For questions about features, operation/performance, parts or service, call 888.781.4657 or
WARNING: You must read this manual carefully and completely before using your grill to ensure
proper operation, proper installation, proper servicing and to reduce the risk of fire, burn hazard
and/ or other injury.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the appli-
ance and immediately call your gas supplier or
your fire department.
Leaking gas may cause a fire or explosion which
can cause serious bodily injury, death, or damage
to property.
WARNING
1. Do not store or use gasoline or other flamma-
ble liquids or vapors in the vicinity of this or
any other appliances.
2. An LP cylinder not connected for use shall not
be stored in the vicinity of this or any other ap-
pliances.
Visit our website at www.profiregrills.com
WARNING
Follow all leak-check procedures carefully in this
manual prior to barbecue operation. Do this even
if the barbecue was dealer-assembled.
WARNING
BEFORE LIGHTING:
Do not ignite this appliance without first reading
the Burner Ignition section of the manual.
THIS GRILL IS FOR OUTDOOR USE ONLY.
If your appliance is a LP unit and stored indoors, de-
tach and leave LP cylinder outdoors.
NOTICE TO INSTALLER: These instructions must
be left with the owner and the owner should keep
them for future use.
MH49347
REV 3/2016
Advertisement
Table of Contents
Related Manuals for ProFire 48G
Summary of Contents for ProFire 48G
- Page 1 Owner’s Manual & Installation Instructions For questions about features, operation/performance, parts or service, call 888.781.4657 or Visit our website at www.profiregrills.com MH49347 WARNING: You must read this manual carefully and completely before using your grill to ensure proper operation, proper installation, proper servicing and to reduce the risk of fire, burn hazard and/ or other injury.
- Page 2 We thank you for buying the “Made In USA” professional ProFire Gas Grill. MODEL IDENTFICATION Your ProFire Gas Grill is identified by a model number and a serial number. Always use both the model and serial numbers when contacting ProFire about your grill. For future reference,...
- Page 3 Never use the grill without the drip pan installed and pushed all the way to the back of the grill. Without the drip pan, hot grease and debris could leak downward and produce a fire hazard. The pressure regulator and hose assembly supplied with the ProFire Gas Grill must be used. Replacement pressure regulators and hose assemblies must be those specified by ProFire.
- Page 4 IMPORTANT GAS SAFETY INFORMATION Each appliance is set and tested at the factory for the type of gas supply to be used. Identify the type of gas, either Natural Gas or LP Gas and make sure that the marking on the data plate (rating plate) matches the gas being sup- plied to the grill.
-
Page 5: Table Of Contents
L.P. HOOK UP AND TANK REQUIREMENTS......8 LOCATION REQUIREMENTS...........9 CUT OUT DIMENSIONS............10 LEAK TESTING................11 ADJUSTING FOR PROPER FLAME........12 INSTALLATION CHECK-LIST..........13 GRILL LIGHTING INSTRUCTIONS........14,15 USING YOUR ProFire GAS GRILL........16,17 Side burners...............16,17 Rear broiler & rotisserie..........17,18 CARE & MAINTENANCE............19,20 TROUBLESHOOTING.............20 PARTS LIST & DIAGRAM............21 WARRANTY................22... -
Page 6: Gas Requirements
Gas conversion kits are available from your dealer or ProFire. When ordering have available the model number, and type of gas (L.P. or Natural) which you need the ProFire grill orificed for. To convert to LP gas the model # will be GCKLP followed by the model # of your grill. To convert to Natural gas the model # will be GCKNAT followed by the model number of your grill. -
Page 7: Natural Gas Hook-Up
Be sure to check on type and size of run, and how deep to bury the line. If the line is too small the ProFire gas grill will not function properly. Any joint sealant used must be an approved type and be resistant to actions of L.P. - Page 8 Use only the type regulator and hose specified by ProFire. Only 20 lb. cylinders equipped with an OPD (Overfill Protection Device) should be used with your ProFire grill. Only one propane cylinder may be located in an enclosure or cart. Extra spare cylinders must be stored outdoors out of the reach of children and outside of any building, garage or other enclosed area.
-
Page 9: Location Requirements
Insulated Sleeve If the ProFire gas grill is to be placed into a combustible enclosure an approved insulated sleeve is necessary and is available from your dealer. Use only the ProFire insulated sleeve which has been designed and tested for this purpose. -
Page 10: Cut Out Dimensions
GRILL AND ACCESSORY CUT-OUT DIMENSIONS FOR BUILT-INS... -
Page 11: Leak Testing
Keep a spray bottle of soapy water near the shut-off valve of the gas supply valve. Spray all the fittings. Bubbles indicate leaks. Although all gas connections on the ProFire grill are leak tested at the factory prior to shipment a complete gas tightness check must be performed at the installation site due to possi- ble mishandling in shipment, or excessive pressure unknowingly being applied to the unit. -
Page 12: Adjusting For Proper Flame
ADJUSTING FOR PROPER FLAME AND EFFICIENCY Each burner is tested and adjusted at the factory prior to shipment. However, variations in the local gas supply or conversion from one gas to another may make it necessary to adjust the burners. The flames of the grill burners should be visually checked. -
Page 13: Installation Check-List
INSTALLATION CHECK LIST NOTE TO THE INSTALLER: BE SURE ALL ITEMS ON THIS LIST HAVE BEEN THOROUGHLY COMPLETED AND CHECKED BEFORE OPERATING THE GRILL. _____ Specified clearances maintained to combustibles. _____ If grill is installed in an island, ventilation openings are provided in island. _____ All internal packaging removed. - Page 14 Inspect the gas supply piping or hose prior to turning the gas on. If there is evidence of cuts, wear, or abrasion, it must be replaced prior to use. The replacement pressure regulators and hose assem- bly must be the type specified by the manufacturer. Do not use the ProFire gas grill if the odor of gas is present.
- Page 15 HOW TO LIGHT YOUR GAS GRILL LIGHTING THE SIDE BURNERS DANGER: Failure to open the lid while igniting the grill, or not waiting 5 minutes to allow the gas to clear if the grill does not light, may result in an explosive flare-up which can cause serious bodily injury or death.
-
Page 16: Using Your Profire Gas Grill
DUAL PURPOSE THERMOMETER All ProFire grills come equipped with a dual purpose thermometer which may be left in place to read the air tempera- ture inside of the closed lid or it can be removed and inserted into the meat that you are grilling. - Page 17 USING YOUR PROFIRE GAS GRILL FLAVOR GRID An exclusive feature of the ProFire gas grill is its stainless steel flavor grid designed to deflect the grease from falling into the burners thereby preventing flare-ups and extending the life of the burners. The perfora- tions in the stainless steel evens out the heat and creates a hot surface for the meat drippings to fall on to.
- Page 18 Once the food is secure insert the skewer into the motor. If needed, remove the grill racks. Place a basting pan under the food. It is normal for the skewer to flex when large cuts of meats are being cooked. However, the ProFire system will accommodate most cuts of meat without needing to remove the cooking grids.
- Page 19 CARE AND MAINENANCE STAINLESS STEEL The ProFire gas grill is made from non-rusting, non-magnetic, type 304 stainless steel. There are many different stainless steel cleaners available. Always use the mildest cleaning methods first, scrubbing in the direction of the grain. To touch up noticeable scratches in the stainless steel, sand lightly with dry 100 grit emery paper or scotch bright pad in the direction of the grain.
-
Page 20: Side Burners
CARE AND MAINTENANCE SIDE BURNERS The side burners are constructed of cast iron with a high heat black coating. Occasional cleaning of the burner ports will be necessary. (See page 11, 16) The burners can be repainted using high heat paint. -
Page 21: Troubleshooting
TROUBLESHOOTING If your ProFire gas grill does not function properly, use the following checklist before contacting your dealer for service. You may save the cost of a service call. PROBLEM WHAT TO CHECK FOR AND DO Grill won't light when the rotary ignit-... -
Page 22: Warranty
ProFire, LLC hereby warrants to the Original Purchaser of the ProFire Gas Grill that it will be free of defects in material and workmanship from the date of purchase as follows: Grill must be registered within 60 days of the date of purchase with ProFire for warranty to be valid. LIMITED LIFETIMED Stainless Steel Body •... -
Page 23: Index
Flare ups Stainless steel Flavor grid 3,19 Temperature Gas requirements Total gas consumption Gas supply 5,6,7 Troubleshooting Gasoline Using the ProFire Grease Utensils Grill & side burners maintenance Ventilation Installation check list Ventilation hoods Insulated sleeve Windy conditions 4,14 Joint sealant... - Page 24 Phone: 262.781.4657 • 888.761.4657 Fax: 262.781.3965 • 888.781.3965 Email: info@profiregrills.com A Division of Modern Home Products Corp. Web Site: www.profiregrills.com ©2015 ProFire, LLC MHP configuration, ProFire Grills, Phoenix are registered trademarks of Modern Home Products Corp #OMPF Printed in U.S.A. April 1, 2018...
