ProFire SDBOPN Owner's Manual

Assembly and maintenance instructions

Advertisement

Quick Links

Owner's Manual
www.newphoenixgrills.com
MODEL:
SDBOPN, SDBOPP
MODEL:
SDBOCN, SDBOCP
YOU MUST READ THIS OWNERS
MANUAL BEFORE OPERATING
YOUR GAS GRILL.
ProFire
Grills
Assembly and Maintenance Instructions
THIS GAS APPLIANCE IS DESIGNED FOR
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open Lid.
4. If odor continues, immedi-
ately call your gas supplier
or your fire department.
FOR YOUR SAFETY
1. Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.
2. An LP cylinder not connect-
ed for use shall not be
stored in the vicinity of this
or any other appliance.
FOR YOUR SAFETY
Follow all leak-test procedures
carefully in this manual before
using. Do this even if the grill
was dealer assembled. Do not
try to light this appliance with-
out reading the "Lighting" in-
structions in this manual.
Perfection by Design
OUTDOOR USE ONLY.
THESE INSTRUCTIONS SHOULD BE LEFT
WITH THE CUSTOMER. KEEP THESES IN-
STRUCTIONS FOR FUTURE REFERENCE.
MODEL:
SDSSOPN, SDSSOPP
MODEL:
SDSSOCN, SDSSOCP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDBOPN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ProFire SDBOPN

  • Page 1 FOR YOUR SAFETY MODEL: MODEL: 1. Do not store or use gasoline SDSSOPN, SDSSOPP SDBOPN, SDBOPP or other flammable vapors and liquids in the vicinity of this or any other appliance. 2. An LP cylinder not connect- ed for use shall not be stored in the vicinity of this or any other appliance.
  • Page 2 Note To Customer: We recommend after each use, you turn the control knobs to HIGH (with the lid closed) and run the grill for approximately 10 minutes. This will allow the accumulated fats and greases to cook off, and avoid a possible flare up on the next use. HINT: The fats and greases are cooked off when no more smoke is flowing from the grill vents.
  • Page 3 SAFETY ment of Transportation (DOT), or the National IMPORTANT! Standard of Canada CAN/CSA-B339 Cylin- Check for compliance to these safety rules be- der, Spheres and Tubes For Transportation of fore each use! Dangerous Goods, and Commission as Appli- -Maintain a minimum clearance of 24 inches cable.
  • Page 4 Well ventilated space, NOT in a building, gar- Phoenix Grill dealer or local gas utility in ac- age, or any other enclosed area. It must be out cordance with all applicable codes. CAUTION: of reach of children. A dust cap MUST be used Any additions, changes, or conversions re- whenever the tank is disconnected from the quired in order for the appliance to satisfactorily...
  • Page 5: What Is Not Covered

    Phoenix Grill WARRANTY LIMITED LIFETIME WARRANTY ON THE FOLLOWING: • Cast Aluminum End Caps • Stainless Steel Top Insert • Stainless Steel Bottom Insert • Control Panel • Stainless Steel or Aluminum Column • Deck/Patio Base • Portable Base • Stainless Steel Cooking Grid • Stainless Steel Fasteners 10-YEAR WARRANTY ON THE FOLLOWING: •...
  • Page 6: Rear View

    GETTING TO KNOW YOUR PHOENIX GAS GRILL Right Side Shelf Heat Indicator Grill Lid Sta-Kool Stainless Steel Handle Left Side Utensil Hooks of Burner Control Electronic Igniter Right Side of Burner Control Drip Pan Drain Valve Column Stainless Black Aluminum Grease Collector Bucket Deck/Patio...
  • Page 7 MHP PHOENIX GRILL SERIES PARTS INFORMATION ITEM QUANTITY PART NO. DESCRIPTION GGEIB Electronic Ignitor (AAA Battery Required) GGIB Ignitor Box Assembly GGK10SD Valve Knob GGTG4 Temperature Gauge HHVLV28SD LP Gas Valve #60 Orifice HHVLV32SD Nat. Gas Valve #53 Orifice OBSSD34...
  • Page 8 Box 2- Black or Stainless Steel Column Box 3- Cast Aluminum Cart or Flat Base The column and base should be assembled first, then Models: SDBOPN Nat. Gas the grill head to the completed base assembly. SDBOPP LP Gas Assemble As Follows:...
  • Page 9 PHOENIX Assembly Instructions CONNECTING GRILL TO COLUMN Models: SDSSOPN Nat. Gas Back of Grill 4 BOLTS 3/4" SDSSOPP LP Gas 4 KEP NUTS Stainless Steel Column with BOLT Fixed Base GRILL INSTALL COLUMN BOTH ENDS HEAT NYLON SHIELD SPACER CONNECTING COLUMN TO BASE TANK LOCKING BAR IN THIS...
  • Page 10 Step 2. At this point you have assembled the Pedestal/ Install the (2) decorative acorn nuts which are packed Column and Base Assembly, and will now proceed to with the control panel knobs, etc. (Do Not Over Tight- the grill head itself, (carton 1.) en).
  • Page 11 Step 7. Reinstall Drip Pan and Drain Valve Step 9. Install Side Shelves Lower the “V” shaped drip pan into the pit with the The shelves are mounted on the right side and left side with the (8) 3/4" x 1/4 x 20 bolts and washers. They drain pipe to the right side, as it will go through the are found in a bag attached to the side shelves.
  • Page 12 First Time After Storage Checklist An obstructed venture tube is not the only cause of “Flashback”, it is the most common cause. There, to avoid this problem, frequent inspection SAFETY and cleaning of the venture tubes is neces- Prior To Use sary, even before the first operation of the Listed below are steps to follow each time you use grill.
  • Page 13: Burner Flame Appearance

    BURNER FLAME APPEARANCE 1. Remove the burner assembly from the grill bottom. See step 25 in the assembly instruction section on how to remove. Burner Flame 2. Bend a stiff wire, (a lightweight coat hanger YELLOW YELLOW works well) into a small hook. Run the hook up through each venture tube past bend and into the burner several times.
  • Page 14: Getting Started

    3. Commercial stainless steel cleaners and polish- you may not notice any grease collecting in the ers also work well, such as MHP’s Stainless Steel grease bucket. However, If you notice grease ac- Cleaner (Part #SSC). Note: Over time the stain-...
  • Page 15: Cooking Times

    Patty 8 Minutes Each tainer(s) by folding heavy gauge aluminum foil into Side an open square or purchase a MHP stainless steel smoker box (part #SDSSST) from your Pork Ribs 60 Minutes Phoenix Dealer. Place one or more containers di-...
  • Page 16: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE If you are having difficulty with your grill, follow this guide to solve some common problems. Problem #1: BURNER(S) WILL NOT LIGHT OR THE GRILL DOES NOT GET HOT ENOUGH. PROBABLE CAUSE SOLUTION A. Propane Cylinder Almost Empty. Have Propane Cylinder Filled.
  • Page 17 NOTES:...
  • Page 18 Brass Bristle Brush Pad Stainless Steel Cleaner #SD14313 #SD14342 #SDSDSCC Brass bristle brush, scraper, Replacement brass brush pad for Specially formulated for MHP rosewood handle and brush head SD14313 stainless steel grills. replacement capability. 8 oz. bottle. 17" overall length.
  • Page 19 Rib/Potato Rack Roast Holder Heavy Aluminum Griddle #SDRR2 #SDRR3 #SDAG Chrome plated accommodates 6 Holds roasts, ham, fowl so heat Heavy-duty griddle perfect for racks of ribs and 6 poatatoes. circulates evenly around meat breakfast French toast, eggs, 12" L x 7-1/4" W for thorough balanced cooking.
  • Page 20 Gas Grills Replacement Grill Parts MHP configuration and ProFire are trademarks of Modern Home Products Corp. Because of constant program of improvements, MHP reserves the right to change specifications and prices without notice. ©2011 Modern Home Products Corporation (10/11) Printed in U.S.A.
