Owner's Manual
YOU MUST READ THIS OWNER'S MAUAL BEFORE
OPERATING YOU GAS GRILL.
NOTICE TO INSTALLER: These instructions must
be left with the owner and the owner should keep
them for future use.
6/2011
ProFire Grills
Assembly and Maintenance Instructions
THIS GAS APPLIANCE IS DESIGNED
FOR OUTDOOR USE ONLY.
If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately
1. Do not store or use gasoline or
2. An LP cylinder not connected
Follow all leak-test procedures
carefully in this manual before us-
ing. Do this even if the grill was
dealer assembled.
Do not try to light this appliance
without reading the "Lighting In-
structions" section of this manual.
DANGER
call your gas supplier or your
fire department.
WARNING
other flammable vapors and liq-
uids in the vicinity of this or any
other appliance.
for use shall not be stored in the
vicinity of this or any other ap-
pliance.
WARNING
WARNING
