A n a l o g C l a s s i c S e r i e s
Master User Guide
Models:
Analog corded lobby hotel telephone - A1100,
Analog corded 1-line hotel telephone - A1210,
Analog corded 2-line hotel telephone - A1220,
Analog corded trimstyle hotel telephone - A1310,
Analog cordless 1-line hotel telephone - A1410,
Analog cordless 2-line hotel telephone - A1420,
Analog cordless charging base - C3000,
Analog cordless 1-line accessory handset - C3100, and
Analog cordless 2-line accessory handset - C3200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A1100 and is the answer not in the manual?

Questions and answers

Related Manuals for VTech A1100

Summary of Contents for VTech A1100

  • Page 1 A n a l o g C l a s s i c S e r i e s Master User Guide Models: Analog corded lobby hotel telephone - A1100, Analog corded 1-line hotel telephone - A1210, Analog corded 2-line hotel telephone - A1220,...

  • Page 2: Important Safety Instructions

    Important safety instructions and injury, including the following: This product should only be connected to the host equipment and never directly to the network such as Public Switch Telephone Never push objects of any kind into this product through the slots in the telephone base or handset because they may touch Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions: Use only the supplied rechargeable battery (BT264392) or replacement battery ®...

  • Page 3: Table Of Contents

    Table of contents Important safety instructions ................................i Parts checklist ....................................1 Telephone layout ....................................2 Analog corded lobby - A1100 Analog corded 1-line - A1210 Analog corded 2-line - A1220 Analog corded trimstyle - A1310 Analog cordless 1-line - A1410...

  • Page 4: Parts Checklist

    Parts checklist Model Name Model Parts included number Analog corded lobby A1100 Telephone Corded Telephone base handset line cord Analog corded 1-line A1210 Telephone Corded Telephone base handset line cord Analog corded 2-line A1220 Telephone Corded Telephone base handset line cord...

  • Page 5: Telephone Layout

    Telephone layout Analog corded lobby - A1100 Telephone line jack Wall mount clip...

  • Page 6: Analog Corded 1-Line - A1210

    Telephone layout Analog corded 1-line - A1210 Telephone line jack MESSAGE WAITING Wall mount clip RINGER VOL Autodial keys PROGRAM PAUSE PAUSE (recessed key) PROGRAM (recessed key) FLASH MUTE +/- VOLUME /SPEAKER HOLD...

  • Page 7: Analog Corded 2-Line - A1220

    Telephone layout Analog corded 2-line - A1220 Telephone line jack MESSAGE WAITING Wall mount clip RINGER VOL Autodial keys PAUSE (recessed key) PROGRAM (recessed key) FLASH MUTE +/- VOLUME /SPEAKER HOLD CONF LINE 1 LINE 2...

  • Page 8: Analog Corded Trimstyle - A1310

    Telephone layout Analog corded trimstyle - A1310 Wall mount clip +/VOLUME/- MESSAGE Handset RINGER TONE coiled cord jack...

  • Page 9: Analog Cordless 1-Line - A1410

    Telephone layout Analog cordless 1-line - A1410 Power jack MESSAGE WAITING Wall mount clip Autodial keys PAUSE (recessed key) PROGRAM (recessed key) REDIAL FLASH /FIND HANDSET MUTE +/- VOLUME /SPEAKER HOLD IN USE CHARGE +/VOLUME/- MESSAGE WAITING TALK HOLD FLASH REDIAL /SPEAKER MUTE...

  • Page 10: Analog Cordless 2-Line - A1420

    Telephone layout Analog cordless 2-line - A1420 Power jack MESSAGE WAITING Wall mount clip Autodial keys PAUSE (recessed key) PROGRAM (recessed key) REDIAL FLASH /FIND HANDSET MUTE +/- VOLUME /SPEAKER HOLD CONF CHARGE LINE 1 LINE 2 +/VOLUME/- MESSAGE WAITING LINE 2 LINE 1 HOLD...

  • Page 11: Analog Cordless Charging Base - C3000

    Telephone layout Analog cordless charging base - C3000 Wall mount clip CHARGE...

  • Page 12: Analog Cordless 1-Line Accessory Handset - C3100

    Telephone layout Analog cordless 1-line accessory handset - C3100 +/VOLUME/- MESSAGE WAITING TALK HOLD FLASH REDIAL /SPEAKER MUTE LOW BATTERY...

  • Page 13: Analog Cordless 2-Line Accessory Handset - C3200

    Telephone layout Analog cordless 2-line accessory handset - C3200 +/VOLUME/- MESSAGE WAITING LINE 2 LINE 1 HOLD CONF FLASH MUTE /SPEAKER REDIAL LOW BATTERY...

  • Page 14: Installation

    Installation Analog corded lobby/1-line/2-line - A1100/A1210/A1220 Telephone base installation Telephone wall jack Telephone Telephone line jack line cord Handset coiled cord jack...
  • Page 15 Installation Analog corded lobby/1-line/2-line - A1100/A1210/A1220 Installation option - converting from desktop to wall mount position To mount the telephone base on the wall: Protruding edge Mounting bracket Turn the mounting bracket upside down so that the mounting eyelet on the bracket is facing in the same direction as the other...

  • Page 16: Analog Corded Trimstyle - A1310

    Installation Analog corded trimstyle - A1310 Telephone installation Telephone wall jack Telephone line cord Handset coiled cord jack After installing the telephone base, mount it on the wall by positioning the eyelets on the telephone base and the mounting bracket...

  • Page 17: Analog Cordless

    Installation Analog cordless 1-line/2-line - A1410/A1420 Telephone base installation Electrical outlet not controlled by a wall switch Telephone RJ-45 line cord cord Telephone wall jack Power adapter Telephone line cord RJ-45 cord Power cord jack CAUTION: hotel -888-907-2007...
  • Page 18 Installation Analog cordless 1-line/2-line - A1410/A1420 Handset battery installation Place the battery with the label THIS SIDE UP To replace the handset cover, align all the tabs on the handset cover against the corresponding grooves on the handset, then Replace handset battery Screw cover Follow the steps in Handset battery installation...
  • Page 19 Installation Analog cordless 1-line/2-line - A1410/A1420 Installation option - converting from desktop to wall mount position To mount the telephone base on the wall: Protruding edge Turn the mounting bracket upside down so that the mounting eyelet on the bracket is facing in the same direction as the other Mount the telephone base on the wall by positioning the eyelets on the telephone base and mounting bracket against the Connect the power cord to the telephone base, plug the power adapter into the electrical outlet not controlled by a wall switch,...

  • Page 20: Analog Cordless Charging Base - C3000

    Installation Analog cordless charging base - C3000 Charging base installation Installation option - desktop position: Power cord Installation option - converting from desktop to wall mount position To mount the charging base on the wall: Protruding edge Turn the mounting bracket upside down so that the mounting eyelet on the bracket is facing in the same direction as the other Mount the charging base on the wall by positioning the eyelets on the charging base and the mounting bracket against the...

  • Page 21: Analog

    Installation Analog cordless 1-line/2-line accessory handset - C3100/C3200 Handset battery installation Place the battery with the label THIS SIDE UP To replace the handset cover, align all the tabs on the handset cover against the corresponding grooves on the handset, then Replace handset battery Screw cover...

  • Page 22: Telephone Settings

    Telephone settings Analog corded lobby/1-line/2-line - A1100/A1210/A1220 Parameter Options User adjustable Handset earpiece volume 1, 2, 3*, 4 Yes (for models A1210 and A1220 only) Speaker volume 1, 2, 3, 4, 5*, 6, 7, 8 Yes (for models A1210 and A1220 only)

  • Page 23: Analog Corded Trimstyle - A1310

    Telephone settings Analog corded trimstyle - A1310 Parameter Options User adjustable Listening volume - handset 1, 2, 3*, 4 Ringer tone Tone 1*, Tone 2, Tone 3 Ringer tone To change the ringer tone: When the telephone is idle, slide the RINGER TONE...

  • Page 24: Analog Cordless A1

    Telephone settings Analog cordless 1-line/2-line - A1410/A1420 Parameter Options User adjustable Listening volume - handset 1, 2, 3, 4*, 5, 6 Speaker volume - handset 1, 2, 3, 4*, 5, 6 Speaker volume - telephone base 1, 2, 3, 4*, 5, 6 Ringer volume - telephone base 1, 2*, 3 Ringer tone - telephone base...

  • Page 25: Telephone Operation

    Telephone operation Analog corded 1-line - A1210 Using the corded handset and the telephone base Receive a call The telephone rings and the MESSAGE WAITING To answer a call using the corded handset: To answer a call using the telephone base: On the telephone base, press /SPEAKER /SPEAKER...

  • Page 26: Analog Corded 2-Line - A1220

    Telephone operation Analog corded 2-line - A1220 Using the corded handset and the telephone base Receive a call The telephone rings and the MESSAGE WAITING To answer a call using the corded handset: To answer a call using the telephone base: /SPEAKER Place a call On the telephone base, lift the corded handset, or press LINE 1, LINE 2, or...
  • Page 27 Telephone operation Analog corded 2-line - A1220 Hold To place a call on hold: HOLD at line key Conference call To initiate a conference call while one call is placed on hold: Once the second party is on the line, press CONF To initiate a conference call while two calls are on hold: Press CONF To terminate a conference call:...

  • Page 28: Analog Corded Trimstyle - A1310

    Telephone operation Analog corded trimstyle - A1310 Receive a call The telephone rings and the MESSAGE To answer a call: Place a call End a call Share a call To share a call: Volume To adjust the listening volume: +/VOLUME/-...

  • Page 29: Analog Cordless 1-Line - A1410

    Telephone operation Analog cordless 1-line - A1410 Using the cordless handset and the telephone base When the cordless handset or the telephone base is in use, the TALK key on the cordless handset and the IN USE Receive a call The telephone rings and the IN USE To answer a call using the cordless handset while it is not on the handset cradle: On the cordless handset, press TALK or...
  • Page 30 Telephone operation Analog cordless 1-line - A1410 Redial To redial the last dialed number from the cordless handset: Press TALK or /SPEAKER REDIAL To redial the last dialed number from the telephone base: Press /SPEAKER REDIAL Call waiting When you hear the call waiting tone during a call, press FLASH on the cordless handset or telephone base to answer the new Press FLASH Mute To mute the microphone:...

  • Page 31: Analog Cordless 2-Line - A1420

    Telephone operation Analog cordless 2-line - A1420 Using the cordless handset and the telephone base Receive a call The telephone rings and the MESSAGE WAITING To answer a call using the cordless handset while it is not on the handset cradle: /SPEAKER To answer a call using the cordless handset while it is resting on the handset cradle: To answer a call using the telephone base:...
  • Page 32 Telephone operation Analog cordless 2-line - A1420 Redial To redial the last dialed number from the handset or telephone base: Press LINE 1, LINE 2 or /SPEAKER REDIAL Call waiting When you hear the call waiting tone during a call, press FLASH on the cordless handset or telephone base to answer the new Press FLASH Mute To mute the microphone:...

  • Page 33: Appendix

    Appendix Troubleshooting Corded telephone The telephone does not work at all. • • There is no dial tone. • • • (charges may I cannot dial out. • • • • The telephone does not ring when there is an incoming call. •...
  • Page 34 Appendix Troubleshooting Cordless telephone The telephone does not work at all. • • • Make sure the battery is installed and charged correctly (pages 13 and 14 • • • LOW BATTERY • • There is no dial tone. • •...
  • Page 35 Appendix Troubleshooting • • Remove and install the battery again and place the cordless Cordless handset beeps and is not performing normally. • • Move the cordless handset closer to the telephone base or adjust the setting of RF transmission power ( ( page 21 •...

  • Page 36: Precautions For Users Of Implanted Cardiac Pacemakers

    ® The RBRC program provides a convenient alternative to placing used nickel-metal hydride batteries into the ® VTech’s participation in RBRC makes it easy for you to drop off the spent battery at local retailers participating ® in the RBRC 1 (800) 8 BATTERY ®...

  • Page 37: Warranty

    How do you get warranty service? meet the terms of this limited warranty, VTech will notify you and will request that you authorize the cost of repair prior to any further What must you return with the Product to get warranty service?
  • Page 38 Appendix FCC, ACTA and IC regulations FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...

  • Page 39: Maintenance

    Appendix FCC, ACTA and IC regulations (continued) Industry Canada Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must Maintenance Taking care of your telephone Avoid rough treatment Avoid water Electrical storms Cleaning your telephone...
  • Page 40 Appendix Analog corded lobby - A1100 Power requirements Line powered 24V or 48V Size Corded handset: Analog corded 1-line/2-line - A1210/A1220 Power requirements Line powered 24V or 48V Message waiting signal Autodial memory Size Corded handset: Analog corded trimstyle - A1310...

  • Page 41: Index

    Index About cordless telephones 33 End a call 22 Analog corded 1-line phone installation 11 End a conference call 24 Analog corded 1-line phone layout 3 Analog corded 1-line phone operation 22 Analog corded 1-line phone settings 19 Analog corded 2-line phone installation 11 Find handset 27 Analog corded 2-line phone layout 4 Flash 19...
