The TPS65680EVM is an evaluation tool for the TPS65680 18-Channel Pattern-Programmable Level
Shifter with Overcurrent Protection for use in large format liquid-crystal display (LCD) display applications
such as TVs and monitors. The TPS65680 supports up to twelve high-voltage clock (GCK) outputs in
charge-sharing or gate-voltage shaping configuration, six high-voltage control outputs for generating start,
clear and reset, and low frequency signals and panel discharge. The evaluation module with its graphical
user interface (GUI) enables the programming of the device from a Microsoft
provides easy access to all 18 outputs, 3 supplies and logic inputs.
This user's guide describes the characteristics, operation and use of the TPS65680 evaluation module
(EVM) and its drive software. This EVM contains TI's 18-channel pattern-programmable level shifter with
overcurrent protection IC TPS65680. The user's guide includes EVM specifications, the recommended test
setup (hardware and software), the schematic diagram, the bill of materials, and the board layouts.
All typical characteristics measurements in the TPS65680 data sheet were done with this evaluation
module.
spacer
spacer
SLVUBB1 – November 2017
Submit Documentation Feedback
ADVANCE INFORMATION
How to Use the TPS65680 Evaluation Module
Copyright © 2017, Texas Instruments Incorporated
SLVUBB1 – November 2017
Windows
®
How to Use the TPS65680 Evaluation Module
User's Guide
7 or 10 PC and
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPS65680 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Texas Instruments TPS65680

  • Page 1 Shifter with Overcurrent Protection for use in large format liquid-crystal display (LCD) display applications such as TVs and monitors. The TPS65680 supports up to twelve high-voltage clock (GCK) outputs in charge-sharing or gate-voltage shaping configuration, six high-voltage control outputs for generating start, clear and reset, and low frequency signals and panel discharge.
  • Page 2: Table Of Contents

    TPS65680 EVM Bill of Materials Trademarks Microsoft, Windows are registered trademarks of Microsoft Corporation. All other trademarks are the property of their respective owners. How to Use the TPS65680 Evaluation Module SLVUBB1 – November 2017 Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated...
  • Page 3: Introduction

    To keep TPS65680 synchronised to the timing controller signals, just 2 digital input signals are necessary: • LN_CLK is the input signal for the TPS65680 internal PLL. This fixed frequency signal is often set to the line frequency. •...
  • Page 4: Features

    ADVANCE INFORMATION Introduction www.ti.com Features • Eases design by providing a simple way to evaluate TPS65680 • Includes pattern examples to ease first evaluation • How-to video available for the first programming steps • The added interface board (USB2ANY) connects the EVM to a Microsoft Windows 7 or 10 PC •...
  • Page 5: Tps65680 Evm Schematic

    1000pF 1000pF 1000pF 1000pF 1000pF 1000pF GSP2 1000pF 1000pF Copyright © 2017, Texas Instruments Incorporated Figure 1. TPS65680 EVM Schematic SLVUBB1 – November 2017 How to Use the TPS65680 Evaluation Module Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated...
  • Page 6: Connector And Test Point Descriptions

    Power Supply SNS + SNS - 2-wire connection SNS + Power Supply SNS - Figure 2. Two- and Four-Terminal Connection How to Use the TPS65680 Evaluation Module SLVUBB1 – November 2017 Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated...
  • Page 7: Input Connectors

    J6, J52, and S2 – LS_CNTRL - Input and GND Connectors The header J6 is the connection for the LS_CNTRL input signal. For programming the TPS65680 this signal needs to be low, if this signal is set high, the IC is in active mode and the device can be controlled via the LN_CLK and LS_START signals.
  • Page 8: Additional Jumpers And Connectors

    With the 10-pin header J53 the EVM connects through the USB2ANY interface box to a PC. The installed GUI communicates through the I2C pins 9 and 10 of J53 with the TPS65680 on the EVM. Pin 1 of J53 can drive LS_CNTRL via S2, pin 2 of J53 connects I2C_SEL to the GUI.
  • Page 9: Software Setup To Change The Output Voltages And Configuration

    Software Operation After the installation of the software, an icon with the name TPS65680 appears on the desktop (if checked within the installation) of the host computer. If it does not, browse the program files in the Start menu for the software.
  • Page 10: Tps65680 Software Window

    ADVANCE INFORMATION Test Setup www.ti.com Figure 3. TPS65680 Software Window How to Use the TPS65680 Evaluation Module SLVUBB1 – November 2017 Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated...
  • Page 11: Tps65680 Evm Assembly Drawings And Layout

    35-μm (1 oz), copper-clad circuit board. All components are on the top side, and all active traces on the top and bottom layers allow you to easily view, probe, and evaluate the TPS65680 IC. Moving components to both sides of the PCB can offer additional size reduction for space-constrained systems.
  • Page 12: Tps65680 Evm Top Layer

    ADVANCE INFORMATION TPS65680 EVM Assembly Drawings and Layout www.ti.com Figure 5. TPS65680 EVM Top Layer How to Use the TPS65680 Evaluation Module SLVUBB1 – November 2017 Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated...
  • Page 13: Tps65680 Evm Bottom Layer (Bottom View)

    ADVANCE INFORMATION TPS65680 EVM Assembly Drawings and Layout www.ti.com Figure 6. TPS65680 EVM Bottom Layer (Bottom View) SLVUBB1 – November 2017 How to Use the TPS65680 Evaluation Module Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated...
