Dwyer Instruments 45158 Specifications-Installation And Operating Instructions

Measure wind speed, temperature, windchill, humidity, dew
point, and % RH with the Model 45158 Pocket Weather Meter.
Measuring modes and display units can be changed at any time. All
functions are controlled with two buttons. The 45158 displays maxi-
mum, average, and current wind speed in knots, meters per minute,
and Beaufort scales. Quickly select temperature measurement in °F or
°C. The compact, rugged weather meter is water resistant, and the unit
also features automatic shut-off. Similar to the standard wind meter,
the 45158 also offers data hold, detailed instruction manual, protective
plastic housing, tripod-mounting connection, and a water resistant hous-
ing that floats. Accessories include a spare battery and a 43˝ lanyard.
METER DESCRIPTION
10
1. Vane impeller
2. Impeller set screw (on rear
of meter)
3. Relative Humidity sensor
4. Temperature sensor
5. LCD display
DWYER INSTRUMENTS, INC.
P.O. BOX 373 • MICHIGAN CITY, INDIANA 46361, U.S.A.
Model 45158 Pocket Weather Meter
Specifications - Installation and Operating Instructions
1
2
3
4
5
6
7
8
9
6. ON/OFF/HOLD key
7. UNITS/MODE key
8. Battery compartment (on
rear)
9. Tripod mounting hole
10. Lanyard (neckstrap)
1-45/64
(43.2)
THIS COMPONENT IS
ON VENDOR MODEL
45158 ONLY
9-3/16
(233.4)
1-55/64
(47)
SPECIFICATIONS
Air Velocity Range: 100 to 5500 ft/min, 0.5 to 28 m/s, 2 to 100
km/h, 1 to 62 mph, 1 to 54.3 knots, 1 to 17 Beaufort.
Temperature/Wind-chill Ranges: 0 to 122°F (0.1°)/-18 to
50°C (0.1°).
Relative Humidity: 10% to 95% (model 45158 only).
Accuracy:
Wind speed: ±3% of reading.
Temperature: ±1.8°F/±1°C.
Relative Humidity: ±5% RH.
Air Velocity Units: m/s; mph; knots; km/hr; ft/min; Beaufort.
Resolution: 0.2 mph.
Sample Time: 1 reading per second.
Averaging: 5, 10, or 13 second intervals.
Water-resistant: to 3 ft (1 meter).
Wind Speed: Limits: 0.5 to 89 mph.
Power: Lithium battery (CR-2032 or equivalent) 400 hour life
expectancy, replaceable.
Auto-off: 30 minutes after last key is pressed.
Impeller: Plastic, replaceable.
Case: Plastic.
Weight: 3 oz (95 g).
Agency Approval: CE.
Range Specifications:
Measurement
mph (miles/hour)
Km/hr (kilometers/hour)
Knots (nautical miles/hour)
m/sec (meters/second)
ft/min (feet/minute)
Beaufort force
Temperature
Relative Humidity
Dew Point
Phone: 219/879-8000
Fax: 219/872-9057
Bulletin 45158
21/32
(24.6)
THIS COMPONENT IS
ON VENDOR MODEL
45158 ONLY
Range
Resolution
1.1 to 62.5 mph
0.2 mph ±(3%rdg+0.4 mph)
1.8 to 100.6 km/h
0.7 km/h ±(3%rdg+1.4km/h)
1.0 to 54.3 knots 0.3 knots ±(3%rdg+0.6knots)
0.5 to 28 m/s 0.1 m/s ±(3%rdg+0.2m/s)
100 to 5500 ft/min 20 ft/min ±(3%rdg+40ft/min)
1 to 17 1 BF ±1
0 to 122°F (-18 to 50°C) 0.1°F/C ±1.8°F (±1°C)
10 to 95% 1% ±5% RH
32 to 122°F (0 to 50°C) 0.1°F/C ±3.6°F (±2°C)
www.dwyer-inst.com
e-mail: info@dwyer-inst.com
Accuracy
