'Options' Menu
From the Measurement Mode, press MENU to access the 'Options' menu. The CAL icon will blink.
Use the ▲▼ buttons to scroll through the following options; detailed instructions follow this list:
CAL Two-Point Calibration
rEC Record setting/recall (select Recoding ON/OFF for MIN, MAX, AVG, and MAX minus MIN)
ALr High-Low Alarm Settings (select ON or OFF and program alarm limits)
Unt Measurement Units (mils or microns)
FEr Substrate Material setting (select ferrous, non-ferrous, or auto sensing)

CAL - Two-Point Calibration

Use the uncoated substrate and the 1006 μm reference film or use two reference films (one
thinner than the other) of known thickness.
Remove the protective plastic coating from the metal reference standards before use.
Note: To clear previously set calibration points, while in the measuring mode, press and hold
ZERO/CLEAR for at least 2 seconds. The LCD will display "0000".
The maximum possible calibration value is 1006 μm (39.6 mils)
1. Turn on the meter by pressing the tip.
2. Press MENU to access the Two-point Calibration mode. 'CAL' will be flashing in the upper
right corner of the display.
3. Press MENU again and the LCD will display Lo in the upper right hand corner.
Use the up and down arrow buttons to set the value to '0' for an uncoated substrate or
to the thickness value of the thinner reference film being used for the calibration.
4. Press MENU/ENTER to confirm the value. The display will flash 'PUSH'.
5. Press the tip of the gauge to the uncoated substrate for '0' or to the substrate with the
thinner reference film. The gauge will beep once. The low value calibration point is now
set.
6. The LCD will display Hi in the upper right hand corner.
Use the up and down arrow buttons to adjust the display to the value of the thicker
reference film. Use the standard coating plate (1006μm/39.6mils) or a known reference
film that is thicker than the first calibration film.
7. Press MENU/ENTER to confirm the reading. The display will flash 'PUSH'.
8. Press the tip of the gauge to the thicker reference film. The gauge will beep once and
then return to the measurement mode. The high value calibration point is now set.
9. The meter is now ready to make measurements.
10. To abort at any time without saving the Two-point Calibration, Press ESC/DEL.
