P E E L I N G & T E A R I N G S U P P L I E S

Use these instructions with your Monarch® 9485 printer. For more information, refer to the

User's Manual.

Note:

When loading supplies, set the paper width guide correctly:

Turn the paper width guide with your finger until the supply guides

L o a d i n g S u p p l i e s f o r P e e l M o d e

With supply loaded, slide the peeler body in the direction shown until you

and see two complete

Press Feed.

TC9485PEELQR Rev. AA 7/15

touch the edges of your supply.

triangles.

2 clicks

hear two clicks

Table of Contents

Need help?

Do you have a question about the Monarch 9485 and is the answer not in the manual?

Page 1 L o a d i n g S u p p l i e s f o r P e e l M o d e With supply loaded, slide the peeler body in the direction shown until you hear two clicks and see two complete triangles. 2 clicks Press Feed. TC9485PEELQR Rev. AA 7/15 ©2015 Avery Dennison. All Rights Reserved.
Page 2 T e a r i n g S u p p l i e s Tear the backing paper (liner) towards the front of the printer against the peel edge (shown in red); either in a left-to-right or right-to-left motion. Peel Edge Backing Paper Label...
